16 Settings on the base unit SPM 2000 LAN

Polytron Headend
SPM 2000 LAN X.X.
Program
← →
S S ervice
↨
S S ervic c e
← → ←
Program
↨ ↨
← L L AN settings →
↨
24
◄ : back ► : forward + confirm
Reset
→
Copykey
IP Address →
Reset
192.168.x.xxx
Subnet Mask →
255.255.255.xxx
Gateway
192.168.x.xxx
Port
100xx
▼▲ : up + down (scroll)
► Press and hold until display is enabled.
Select Service mode by ▼▲ and confirm with ► !
Select LAN settings by ▼▲ and confirm with ► !
Choose individual digit of the IP address by ◄► and select number by ▼▲.
Attention: by pressing ► at the end of the line the data will be confirmed!
Choose digit of the Subnet Mask by ◄► and select number by ▼▲.
Attention: by pressing ► at the end of the line the data will be confirmed!
Choose digit of the Gateway by ◄► and select number by ▼▲.
→
Attention: by pressing ► at the end of the line the data will be confirmed!
Enter the gateway address of the router.
→
Choose individual digit of the Port by ◄► and select number by ▼▲.
Attention: by pressing ► at the end of the line the data will be confirmed!
