LCD Display

E
F
G
H
I
Item
A Main Numeric Display
B Alternate Numeric Display
C Tank Capacity Percent Indication
D Units Indicators
E Sound Mute Indicator
"Floating" Negative Indicator (Indicates weight removed from
F
platform)
G Battery Level Indicator
H Fast Adjustment Indicator
I Set Mode Indicator
J Tank Capacity Mode Indicator
K Run Mode Indicator
L Hold Mode Indicator
M Program Complete Indicator
N Calibration Mode Indicator
O Valve Open/Closed Indicator for use with REF-METER-PLUS
P Resolution Indicator
A
J
K L
M
B
O P
N
Function
REF-METER User's Guide
C
D
3
