Refco REF-METER Bedienungsanleitung Seite 10

REF-METER User's Guide
Over Range Indication
If the weight applied to the weighing platform exceeds the maximum capacity of the
REF-METER (100 kg), a single "1" will be shown on the left side of the display. To
prevent damage to the REF-METER, immediately remove the weight from the
platform.
Hold Mode
A special feature of the REF-METER allows the emptying or replacing bins or
containers used for weighing without affecting the weight shown on the display.
This Hold Mode may be used as follows:
1. Allow load to settle until display is steady.
2. Press . The current weight is now locked on the display.
3. Remove, empty, or replace objects, bins, or containers on the platform.
4. Wait 5 seconds for the new load to stabilize.
5. Press . Measurements will continue from where they left off prior to initiating
Hold Mode.
Programming
With the REF-METER, a programmable threshold weight will sound an alarm. The
alarm will sound when the displayed weight (either positive for increasing weight, or
negative for decreasing weight) equals the programmed weight. To program the
alarm, perform the following steps:
1. Set up the REF-METER with the desired units and resolution as described in the
Quick Sta rt Setup section above.
2. If measuring decreasing weight, place the objects or container with the objects or
material that will be removed on the weighing platform.
3. Press to start the SET Mode, indicated by the SET enunciator on the LCD
display.
8
English
