ENGLISH
OPERATION
Use of keys
Increases and decreases the
temperature.
See the selected temperature.
PROGRAMMING
The system allows you to modify and adjust the
temperature between 90 and 450ºC (190 and
840ºF). These are the factory pre-selected
temperatures:
- Minimum temperature: 90ºC
- Maximum temperature: 400ºC
In order to modify the station and tool parameters
and have access to the counters, you must hold
the SELECT key for 3 seconds. The PIN number
must be entered when you need to change a
station parameter. Default PIN number: 0105.
You will find the operation diagrams are on the
following pages.
Display messages
- HIBERNATION: The station is in hibernation
mode.
- OPEN CIRCUIT. Heating element with open
circuit. Possible causes:
The cartridge has not been inserted correctly
in the tool.
Damaged cartridge.
- MAXIMUM POWER. The maximum available
power has been exceeded for too long - e.g.
in very thick and repetitive soldering jobs.
- SHORTCIRCUIT. Short circuit in the system.
Possible causes:
Short circuit in the cartridge or in the handpiece.
- WRONG TOOL.
Possible causes: use of a tool which is not
compatible with the station.
- OVERLOAD. To prevent the station from
overheating, you must wait and the station will
automatically reset.
Possible causes: excesive power demand.
Once you correct the above mentioned causes,
the station will start working automatically, except
if there is an excess in energy supply (MAXIMUM
POWER). In this case, the station has to be
switched off and restarted.
