Structure of AD 2950 soldering station
The AD 2950 has 3 basic modules giving you full
flexibility for choosing what you need for the work
in hand, the modules being supplied separately.
Control unit
- AD 2950 230V
- AD 2950 120V
- AD 2950 100V
Handpieces
- 2210
Power: 20W. For high precision work, SMD, etc.
- 2245
Power: 50W. For general soldering work.
One version of 2245 soldering iron handpiece
covered with a heat insulator is available.
- 2245 comfort handpiece
Other handpieces:
- 2245 comfort handpiece 3 mt
- 2245 handpiece with set screw Ref. 2245130
- 2245 soft grip handpiece
- 2245 hard grip handpiece
Cartridges
- 2210 cartridge range (for the 2210 handpiece)
on page 52.
- 2245 cartridge range (for the 2245 handpiece)
on page 50.
The 2210 and 2245 handpieces and cartridges
comply with the MIL-SPEC-2000 referring to the
potential difference between the soldering tip and
ground connection, must be less than 2 mV.
For a station to work properly, a control unit, a
handpiece and one cartridge are needed.
AD 2950 control unit
The station is supplied with:
- Control unit which incorporates a stand with
sponge and cartridge extractor.
- Connection cable to mains.
- Instructions manual.
- Transport packaging.
Technical specifications
- Temperature selection from 90 to 450°C or
190 to 840ºF (±5%).
- Power: 75W.
- Safety transformer, mains separator and
double isolation, with integrated temperature
protection fuse.
Ref. 2950200
- AD 2950 230V control unit
Ref. 2950100
Input: 230V 50Hz. Output: 24V
Ref. 2950110
- AD 2950 120V control unit
Input: 120V 60Hz. Output: 24V
- AD 2950 100V control unit
Ref. 2210000
Input: 100V 60Hz. Output: 24V
- Total weight of unit: 2.6 Kgs (6,5lbs).
Ref. 2245000
- ESD protected housing.
Typical surface resistance: 10
square.
- Complies with CE standards on electrical
safety, electromagnetic compatibility and
Ref. 2245110
antistatic protection.
- RoHS compliant.
Ref. 2245120
- Equipotential connector and the tool tip are
connected to station mains ground supply for
Ref. 2245140
ESD protection.
Ref. 2245150

RECOMMENDATIONS FOR USE

For soldering
- Preferably select a temperature below
350°C (662ºF). Excess temperature reduce
tip life.
- The tip must be well tinned for good heat
conduction.
Safety measures
- Place the tool back on its stand in order to
let it cool down before you store it.
3
This product should not be thrown in the
garbadge.
ENGLISH
Ref. 2950200
Ref. 2950100
Ref. 2950110
5 -10 11 Ohms/
