Parts List
Ersatzteileliste
Parts List
Parts #
Description
PRECUT FOAM BUMPER GRAY (RS4)
6274
6543
RACING SHOCK SPRING 14x25x1.5mm 6.5COILS(SIL/2pcs)
6544
RACING SHOCK SPRING 14x25x1.5mm 6 COILS(GOLD/2pcs)
6820
SILICONE O-RING P-3 (CLEAR/8pcs)
61644
SERVO SAVER SET (BODY/HONE)
39 TOOTH PULLEY (ONE-WAY)
61051
61087
SOLID AXLE CUP (STEEL/2pcs)
61092
WHEEL NUT M4 SERRATED (PURPLE/4pcs)
61148
DIFF THRUST WASHER (2pcs)
DIFFERENTIAL THRUST BALL 1/16"
61149
61237
BEARING HOLDER PARTS
61246
TURNBUCKLE 3x24mm (2pcs)
61247
TURNBUCKLE 3x34mm (2pcs)
61327
CYLINDER UPPER CAP (PURPLE/2pcs)
CYLINDER LOWER CAP (PURPLE/2pcs)
61328
61338
44mm ALUMINUM UNIVERSAL DRIVE SHAFT (PURPLE/1pc)
61627
DIFF RING (2pcs)
67712
UPPER BULK HEAD SET (PURPLE)
SHOCK BODY
67716
67717
GRAPHITE SUSPENSION ARM SET
67718
SWAY BAR HOLDER
67721
39T PULLEY (PRO SPEC BALL DIFF)
CERAMIC DIFF BALL (3mm/12pcs)
67722
DIFF SCREW SET (PRO SPCE BALL DIFF)
67725
67841
Li-PO BATTERY HOLDER SET
68703
BELT 171T
68704
BELT 64T
CENTER PULLEY 20T (SPUR GEAR HOLDER)
68705
68706
CENTER PULLEY 20T
68707
SWAY BAR SET (1.2mm/1.3mm/1.4mm)
68710
MAIN CHASSIS (2.5mm)
UPPER DECK (2.0mm)
68711
FRONT SHOCK TOWER
68713
68714
REAR SHOCK TOWER
68715
GRAPHITE BUMPER BRACE
68716
LOWER BULK HEAD (2pcs)
MOTOR MOUNT
68717
68718
MIDDLE BLOCK
68721
SOLID AXLE SET
68723
ALUMINUM WASHER 4x6x1.0mm (4pcs/PURPLE)
DIFF OUTDRIVE SET (POM)
68725
68726
BALL DIFFRENTIAL SET
68727
CENTER SHAFT 4x26mm
68728
HB TCX DECAL
68734
UNIVERSAL DRIVE SHAFT (46mm/1pc)
STEERING ARM SET
68735
68739
CENTER SHAFT PIN 2x9.8mm (10pcs)
68745
HB RACING SPUR V2 GEAR 115 TOOTH (64PITCH)
68755
PIVOT BLOCK (FR/PURPLE)
PIVOT BLOCK (RF/PURPLE)
68756
73507
CARBON GRAPHITE BLOCK AND HUB SET
73510
SHOCK PARTS/BALL END SET
73513
BUMPER/BODY POST SET
73518
CARBON GRAPHITE C HUB SET (4 DEGREES)
BLADDER 12x3.5mm (FLAT TYPE/4pcs)
73523
75106
BODY CLIP (6mm/BLACK/20pcs)
75115
BALL STUD 4.3x10.3mm (2mm SOCKET/4pcs)
75116
BALL STUD 4.3x13mm (2mm SOCKET/4pcs)
SUSPENSION SHAFT 2.5x24.5mm (2pcs)
75119
75121
PIVOT BALL 3x5mm (4pcs)
75122
STEERING BLOCK BUSHING (4pcs)
75161
PIVOT BLOCK (2.5 DEGREES/ALUMINUM/PURPLE)
PIVOT BLOCK (3 DEGREES/ALUMINUM/PURPLE)
75162
UNIVERSAL AXLE (2pcs)
75187
75188
UNIVERSAL Rebuild KIT (2pcs)
A165
SPRING 6x7x1.5mm (DIFFERENTIAL) BLACK (2pcs)
A302
HEAVY-DUTY BALL CUP 4.3x18mm (8pcs)
BALL BEARING 3x6x2.5mm (FLANGED/2pcs)
B012
B017
BALL BEARING 4x8x3mm (2pcs)
B020
BALL BEARING 5x8x2.5mm (2pcs)
B021
BALL BEARING 5x10x4mm (2pcs)
BALL BEARING 10x15x4mm (2pcs)
B030
SHAFT 3x45mm, 2pcs (CYCLONE)
HB70712
HB70720
CYLINDER NUT (BLACK/2pcs)
HB70721
HIGH GRADE SHOCK SHAFT, 28mm, 2pcs (CYCLONE)
HB70722
SHOCK PISTON (1.2), 2pcs (CYCLONE)
ROD GUIDE, 2pcs (CYCLONE)
HB70723
HB70742
ALUMINUM HEX HUB SET (CLAMP TYPE/4pcs/CYCLONE)
Z082
FLAT HEAD SCREW M3x8mm (HEX SOCKET/10pcs)
Z083
FLAT HEAD SCREW M3x10mm (HEX SOCKET/10pcs)
ANTENNA PIPE SET
Z150
Z155
DIFFERENTIAL LUBE (SILICONE)
Z156
GRAY DIFFERENTIAL LUBE (FOR DIFF SMALL BALLS)
Z203
WASHER M3x6mm (10pcs)
Z216
BUTTON HEAD SCREW M3x15mm (HEX SOCKET/4pcs)
CAP HEAD SCREW M2x5mm (10pcs)
Z234
Z242
E CLIP E2mm (20pcs)
Z264
PIN 2x10mm SILVER (10pcs)
Z350
BUTTON HEAD SCREW M3x5mm (HEX SOCKET/10pcs)
BUTTON HEAD SCREW M3x8mm (HEX SOCKET/10pcs)
Z352
Z353
BUTTON HEAD SCREW M3x10mm (HEX SOCKET/10pcs)
Z354
BUTTON HEAD SCREW M3x12mm (HEX SOCKET/10pcs)
Z356
BUTTON HEAD SCREW M3x18mm (HEX SOCKET/10pcs)
Z653
NUT M3 (6pcs)
LOCK NUT M3 THIN TYPE (4pcs)
Z676
Z700
SET SCREW M3x3mm (6pcs)
Z724
SET SCREW M4x8mm (ROUND POINT/6pcs)
Z775
SET SCREW TP3.2x5mm
ALUMINUM WASHER 3x6x0.75mm (PURPLE/10pcs)
Z814
Z816
ALUMINUM WASHER 3x6x1.5mm (PURPLE/10pcs)
Z817
ALUMINUM WASHER 3x6x2.0mm (PURPLE/10pcs)
Z825
WASHER M4x6x0.2mm (COPPER/10pcs)
WASHER 5x7x0.2mm (10pcs)
Z852
Liste de pièces
パーツリスト
Ersatzteileliste
Nummer
Beschreibung
ANGEPASSTER RAMMER GRAU RS4
6274
6543
DAEMPFERFEDER RACING 14x25x1.5mm 6.5WDG. (SIL/2ST)
6544
DAEMPFERFEDER RACING 14x25x1.5mm 6WDG. (GOLD/2ST)
6820
SILIKON O-RING P-3 (TRANSPARENT/8 ST.)
61644
SERVO SAVER SET (CYCLONE 12)
RIEMENRAD 39Z (FREILAUF) CYCLONE
61051
61087
CUP JOINT F. STARRACHSE (STAHL/2ST/CYCONE)
61092
RADMUTTER M4 (GERIFFELT/LILA/4ST)
61148
DRUCKLAGERSCHEIBEN 2.8x5.8x1mm (2ST)
DRUCKLAGERKUGELN 1/16
61149
61237
LAGERHALTER TEILE (CYCLONE S)
61246
SPURSTANGE 3x24mm (2 ST/CYCLONE S)
61247
SPURSTANGE 3x34mm (2 ST/CYCLONE S)
61327
DAEMPFERKAPPE OBEN (LILA/2 ST) CYCLONE
DAEMPFERKAPPE UNTEN (LILA) CYCLONE
61328
61338
ALUMINIUM KARDAN 44MM (LILA/1 ST) CYCLONE
61627
DIFFERENTIAL-RINGE (2ST/CYCLONE 12)
67712
OBERES DIFFGEHAEUSE SET (LILA/CYCLONE TC)
DAEMPFERGEHAEUSE (2ST/CYCLONE TC)
67716
67717
SCHWINGEN SET (KOHLEFASERVERSTAERKT/CYCLONE TC)
67718
STABILISATOR HALTER
67721
RIEMENRAD 39Z (PRO SPEC DIFF)
KERAMIK DIFFERENTIALKUGELN (3mm/12ST)
67722
DIFFERENTIAL SCHRAUBE M2.6x31mm (PRO SPEC DIFF)
67725
67841
LIPO AKKUHALTER SET (TCX)
68703
RIEMEN 171Z (TCX)
68704
RIEMEN 64Z (TCX)
RIEMENRAD 20Z/HAUPTZAHNRADHALTER (TCX)
68705
68706
RIEMENRAD 20Z (TCX)
68707
STABILISATOR SET (1.2mm/1.3mm/1.4mm/TCX)
68710
CHASSIS (2.5mm/TCX)
OBERDECK (2.0mm/TCX)
68711
DAEMPFERBRUECKE VORNE (TCX)
68713
68714
DAEMPFERBRUECKE HINTEN (TCX)
68715
RAMMER-STREBE KOHLEFASER (TCX)
68716
UNTERER BULKHEAD (1ST/TCX)
MOTORHALTER (TCX)
68717
68718
MITTELBLOCK (TCX)
68721
STARRACHSEN SET (TCX)
68723
ALUMINIUM SCHEIBE 4x6x1.0mm (4ST/LILA)
DIFF ABTRIEB SET (POM/TCX)
68725
68726
KUGELDIFFERENTIAL SET (TCX)
68727
MITTELWELLE 4x26mm (TCX)
68728
HB TCX AUFKLEBER
68734
KARDANKNOCHEN (46mm/1ST/TCX)
LENKHEBEL SET (TCX)
68735
68739
MITTELWELLEN STIFT 2x9.8mm (10ST/TCX)
68745
RACING HAUPTZAHNRAD V2 115 ZAEHNE (64DP)
68755
QUERLENKERHALTER V/H (ALUMINIUM/LILA)
QUERLENKERHALTER H/V (ALUMINIUM/LILA)
68756
73507
LENKHEBEL/TRAEGER (KOHLEFASERVERSTAERKT)
73510
DAEMPFERTEILE/KUGELKOPF SET
73513
RAMMER/KAROSSERIEHALTER SET
73518
LENKHEBELTRAEGER (4 GRAD/KOHLEFASERV.)
DAEMPFERMEMBRAN 12x3.5mm (FLACH/4 ST)
73523
75106
KAROSSERIEKLAMMERN (6mm/SCHWARZ/20ST)
75115
KUGELKOPF 4.3X10.3mm (2mm INBUS/4ST)
75116
KUGELKOPF 4.3x13mm (2mm INBUS/4ST)
ACHSSTIFTE 2.5x24.5mm (2ST)
75119
75121
KUGELKOPF 3x5mm (4ST)
75122
LENKUNGSLAGER (4ST)
75161
QUERLENKERHALTER (2.5 GRAD/ALU/LILA)
QUERLENKERHALTER (3 GRAD/ALU/LILA)
75162
KARDAN ACHSE (2ST/PRO4/CYCLONE)
75187
75188
KARDAN WARTUNGS SET (2ST/PRO4/CYCLONE)
A165
DIFF-FEDER 6x7x1.5mm SCHWARZ (2 ST.)
A302
KUGELPFANNE 4.3x18mm (8 ST.)
KUGELLAGER 3x6x2.5mm (MIT FLANSCH/2ST)
B012
B017
COMPETITION LOW FRICTION KUGELLAGER 4x8x3mm 2 ST.
B020
COMPETITION LOW FRICTION KUGELLAGER 5x8x2.5mm 2 ST
B021
COMPETITION LOW FRICTION KUGELLAGER 5x10mm (2 ST.)
COMPETITION LOW FRICTION KUGELLAGER 10x15x4mm 2 ST
B030
ACHSSTIFT 3x44.5mm (2ST/CYCLONE)
HB70712
HB70720
DAEMPFER EINSTELLMUTTER (SCHWARZ/2ST/CYCLONE)
HB70721
KOLBENSTANGE HIGH GRADE 28mm (2ST/CYCLONE)
HB70722
KOLBENPLATTEN (2L/1.2mm/2ST/CYCLONe)
KOLBENSTANGENFUEHRUNG (2ST/CYCLONE)
HB70723
HB70742
ALU FELGENMITNEHMER ZUM KLEMMEN (CYCLONE)
Z082
SENKKOPFSCHRAUBE M3x8mm (INBUS/10ST)
Z083
SENKKOPFSCHRAUBE M3x10mm (INBUS/10ST)
ANTENNENROHRSET
Z150
Z155
DIFFERENTIAL FETT
Z156
GRAUES DIFFERENTIALFETT
Z203
M3X6 UNTERLAGSCHEIBE (10 ST.)
Z216
FLACHKOPFSCHRAUBE M3x15mm (INBUS/4ST)
INBUSSCHRAUBE M2x5mm (10ST)
Z234
Z242
E-CLIP E2mm SILBER 20ST.
Z264
STIFT 2x10mm SILBER (10 ST.)
Z350
FLACHKOPFSCHRAUBE M3x5mm (INBUS/10ST)
FLACHKOPFSCHRAUBE M3x8mm (INBUS/10ST)
Z352
Z353
FLACHKOPFSCHRAUBE M3x10mm (INBUS/10ST)
Z354
FLACHKOPFSCHRAUBE M3x12mm (INBUS/10ST)
Z356
FLACHKOPFSCHRAUBE M3x18mm (INBUS/10ST)
Z653
MUTTER M3 6ST.
STOPPMUTTER M3 (FLACH)
Z676
Z700
MADENSCHRAUBE M3x3mm (6ST)
Z724
MADENSCHRAUBE M4x8mm (6ST)
Z775
MADENSCHRAUBE TP3.2x5mm
ALUMINIUM UNTERLAGSCHEIBE 3x6x0.75mm (LILA/10 ST.)
Z814
Z816
ALUMINIUM UNTERLAGSCHEIBE 3x6x1.5mm (LILA/10 ST.)
Z817
ALUMINIUM UNTERLAGSCHEIBE 3x6x2.0mm (LILA/10 ST.)
Z825
UNTERLAGSCHEIBE M4x6x0.2mm (KUPFER/10 ST.)
UNTERLAGSCHEIBE 5x7x0.2mm (10ST.)
Z852
