Fitting sockets
• Align the hole (8) in the side of the socket with
the detent pin (9) on the anvil.
• Push the socket (10) onto the anvil (3) until it
snaps into place. Tap it lightly if required.
Removing sockets
• Depress the detent pin (9) through the hole (8) in
the socket and pull thesocket off the anvil.
Forward/reverse slider (fig. B)
• To select forward or reverse rotation, use the
forward/reverse slider (2) as shown
(see arrows on tool).
Always wait until the motor has come to
a complete standstill before changing the
direction of rotation.
The first time the tool is run after changing the direction
of rotation, a click may be heard on start up.
Instructions for use
Always observe the safety instructions
and applicable regulations.
Prior to operation:
• Depending on your tool, select the appropriate
bit or socket.
• Make sure your battery pack is (fully) charged.
Switching on and off (fig. A)
• To run the tool, press the variable speed switch
(1). The pressure exerted on the variable speed
switch determines the tool speed.
• To lock the tool in off position, move the forward/
reverse slider (2) to the central position.
Operation (fig. A)
• Select forward or reverse rotation using slider (2).
• Depending on the application, follow either of the
below instructions.
• Press the variable speed switch (1).
• After tightening, check torque with a torque
wrench.
Screwdriving
• Place the tip of the driver bit in the screw head.
• Keeping the tool in line with the screw,
apply forward pressure to the tool as it contacts
the work surface.
Nutsetting
• Place the socket over the head of the bolt or nut.
• Hold the tool in line with the fastener.
Tightening time
This tool tightens most fasteners in few seconds.
The proper tightening time in relation to torque must
be determined by experience.
Excessive tightening may damage the tip
of the driver bit and the head of the screw.
Optional accessories
Use only dedicated impact accessories with your tool.
Consult your dealer for further information on the
appropriate accessories.
Battery packs
Voltage
18
Charger
Voltage
9 - 18
Maintenance
Your D WALT power tool has been designed to
E
operate over a long period of time with a minimum
of maintenance. Continuous satisfactory operation
depends upon proper tool care and regular cleaning.
Lubrication
Your power tool requires no additional lubrication.
Cleaning
• Unplug the charger before cleaning the housing
with a soft cloth.
E N G L I S H
NiCd NiMH
DE9095 DE9039
DE9096
NiCd NiMH
DE9116 DE9116
