PARAMETERS
Code Description
P01 Complete cycle operating mode 0: sequential
P02 Complete operating mode
automatic timed closing
P03 Pedestrian cycle operating
mode
P04 Short automatic closing time
delay in pedestrian cycle
P05 Long automatic closing time
delay in pedestrian cycle
P07 Cell safety input
P09 Programmable safety input
P10 Programmable safety input -
function
P11 Programmable safety input -
action
P12 Orange warning light
P13 Area lighting output
P14 Area lighting time delay
P15 Auxiliary output
P16 Auxiliary output time delay
P17 Lock output
P18 Lock release (Control Box 3S
Axovia only)
P19 Closing speed
P20 Opening speed
P21 Closing slowdown zone
P22 Opening slowdown zone
P23 M1/M2 shift when closing
P24 M1/M2 shift when opening
P25 M1 closing torque limitation
P26 M1 opening torque limitation
P27 M1 closing slowdown torque
limitation
P28 M1 opening slowdown torque
limitation
P29 M2 closing torque limitation
P30 M2 opening torque limitation
P31 M2 closing slowdown torque
limitation
P32 M2 opening slowdown torque
limitation
P37 Wired control inputs
P39 Additional thrust when closing
(Control Box 3S Ixengo only)
P40 Coupling speed when closing
P41 Coupling speed when opening
2
Values (bold = default)
1: sequential + timed close
2: semi-automatic
3: automatic
4: automatic + cell blocking
5: deadman's control (wire)
0 to 30 (time delay value = value x 10 s)
2: 20 s
0: identical to complete cycle operating
mode
1: without automatic closing
2: with automatic closing
0 to 30 value x 10 s = time delay value)
2: 20 s
0 to 99 (value x 5 min. = time delay value )
0: 0 s
0: inactive
1: active
2: active with autotest via test output
3: active with autotest via power supply
switching
4: bus cells
0: inactive
1: active
2: active with autotest via test output
3: active with autotest via power supply
switching
0: active closing
1: active opening
2: active closing + ADMAP
3: all movement disabled
0: stop
1: stop + partial reversal
2: stop + complete reversal
0: no warning
1: with 2 s warning prior to movement
0: inactive
1: controlled operation
2: automatic + controlled operation
0 to 60 value x 10 s = time delay value)
6: 60 s
0: inactive
1: automatic: gate open indicator light
2: automatic: timed bistable
3: automatic: one-touch
4: controlled: bistable (ON-OFF)
5: controlled: one-touch
6: controlled: timed bistable
0 to 60 value x 10 s = time delay value)
6: 60 s
0: active 24V one-touch
1: active 12V one-touch
0: inactive
1: active
1: slowest speed
10: fastest speed
Default value:
- Control Box 3S Axovia: 5
- Control Box 3S Ixengo: 6
0: zero slowing (only on Ixengo L 24V)
1: shortest slowdown zone
5: longest slowdown zone
Default value: 1 (2 for Ixengo L 24V)
0: zero shift (only on Ixengo L 24V)
1: minimum shift
10: maximum shift
Adjusted at the end of auto-programming
1: minimum torque
10 (Axovia) or 20 (Ixengo): maximum torque
Adjusted at the end of auto-programming
0: complete cycle mode - pedestrian
cycle
1: opening mode - closing
0: no thrust
1: with thrust (thrust of 2.5 sec after detection
of end limit)
1: slowest speed
4: fastest speed
Default value: 2
OPERATING CODES
Code Description
Setting
C1 Awaiting command
C2 Gate opening
C3 Awaiting gate closure
C4 Gate closing
C6 Detection in progress for cell
safety
C8 Detection in progress for program-
mable safety
C9 Detection in progress for emer-
gency stop safety
PROGRAMMING CODES
Code
H0 Awaiting setting
Hc1 Awaiting setting + 9.6 V power supply
Hu1 Awaiting setting + 24 V power supply
H1 Awaiting start of auto-programming
H2 Auto-programming mode - opening
H4 Auto-programming mode - closing
F0 Awaiting remote control memorisation for operation in complete opening mode
F1 Awaiting remote control memorisation for operation in pedestrian opening
mode
F2 Awaiting remote control memorisation for remote lighting control
F3 Awaiting remote control memorisation for auxiliary output control
ERROR AND BREAKDOWN CODES
Code Description
E1 Cell safety autotest fault
E2 Programmable safety autotest
fault
E4 Obstacle detection when opening
E5 Obstacle detection when closing
E6 Cell safety fault
E8 Programmable safety fault
E9 Thermal protection
E10 Motor short circuit protection
E11 24V power supply short protection Check the wiring of the peripherals connect-
E12 Hardware fault
E13 Accessories power supply fault
E14 Intrusion detection
E15 Fault when the control box
supplied by the backup battery is
first switched on
ACCESSING MEMORISED DATA
To access memorised data, select parameter "Ud" then press "OK".
Data
U0 to U1 Overall complete opening cycle counter
U2 to U3 Complete opening cycle counter since last auto-programming
U6 to U7 Cycle counter with overall obstacle detection
U8 to U9 Cycle counter with obstacle detection since the last auto-programming
U12 to U13 Partial opening cycle counter
U14 to U15 Reset movement counter
U20 Number of remote controls memorised for complete opening control
U21 Number of remote controls memorised for pedestrian opening control
U22 Number of remote controls memorised for remote lighting control
U23 Number of remote controls memorised for auxiliary output control
U24 0 = no system key present, 1 = system key present
d0 to d9 Log of the last 10 faults (d0 most recent - d9 oldest)
dd To clear the fault log: press and hold "OK" for 7 s.
CONTROL BOX 3S io
Code Description
C12 Current reinjection in progress
(Control Box 3S Axovia only)
C13 Safety device autotest in progress
C14 Permanent complete opening wire
control input
C15 Permanent pedestrian opening
wire control input
C16 BUS cell programming refused
Cc1 9.6 V power supply
Cu1 24 V power supply
Description
Solution?
Check the "P07" parameter setting. Check
the wiring of the cells.
Check the "P09" parameter setting. Check
the programmable safety input wiring.
Check that no obstacles are causing the
cells or safety edge to detect.
Check that "P2" is correctly configured
in relation to the device connected to the
safety input.
Check the safety device wiring.
Check that the photoelectric cells are
correctly aligned.
Check the motor wiring.
ed to terminals 21 to 26 then disconnect the
power supply for 10 seconds.
N.B.: maximum accessories consumption
= 1.2 A
Request a gate movement. If the fault is still
present, contact Somfy.
N.B.: maximum accessories consumption
= 1.2 A
Check the consumption of the connected
accessories.
Normal operation (attempted intrusion,
current reinjection activated, etc.)
Disconnect the backup battery and connect
the control box to the mains to switch it on
for the first time.
Description
