3. Specifications

3. Specifications

3.1 Measuring ranges

Relative pressure
bar Measuring range
Overpressure limit
Burst pressure
psi Measuring range
Overpressure limit
Burst pressure
Vacuum tightness
Yes

3.2 Output signals

Signal type

CANopen

J1939

3.3 Voltage supply

Power supply
DC 10 ... 30 V
Total current consumption
< 40 mA
WIKA operating instructions pressure sensor, model MHC-1
0 ... 60 0 ... 100
120 200
240 400
0 ... 1,000 0 ... 1,500
1,740 2,900
3,480 5,800
Signal
Device profile DS-404
SAE J1939
0 ... 160 0 ... 250
320 500
640 1,000
0 ... 2,000 0 ... 3,000
4,000 6,000
9,280 14,500
0 ... 400 0 ... 600
800 1,200
1,600 2,400
0 ... 5,000 0 ... 10,000
10,000 17,400
23,200 34,800
