General

The Electric Conveyor Toaster is designed for ease of
operation. Perform the following procedure to operate the
toaster.
WARNING
Read all safety messages in the IMPORTANT SAFETy
INFORMATION section before operating this equipment.
1. Plug the unit into a properly grounded electrical receptacle
of the correct voltage, size, and plug configuration. See the
SPECIFICATIONS section for details.
2. Move the feed ramp to the desired position.
• For automatic feeding, move the feed ramp to the
automatic feed position. Bread products enter the
toaster by placing them on the feed ramp and releasing.
• For manual feeding, rotate the feed ramp up until it rests
on top of the unit. Bread products can be loaded
manually by placing directly on the conveyor belt.
Automatic Feed
Position
Toast Feed Ramp
3. Move the selector switch to the desired toasting setting.
• To toast both sides of the bread, place the selector
switch in the BREAD position.
• To toast the top of the bread only, place the selector
switch in the BUN position.
NOTE: The Power ON (I) Indicator light will glow after a
toasting selection is made.
COLOR CONTROL
Form No. TMCEM-0212
Manual Feed
Position
Power ON (I)
Indicator
Light
Knob
Control Panel
4. Turn the COLOR CONTROL knob to the lightest position
while the unit heats up.
NOTE: Allow approximately 15 to 20 minutes for a warm-up
period.
BURN HAzARD: Some exterior surfaces on unit will get
hot. Use caution when touching these areas.
5. After warm-up period, set the COLOR CONTROL knob to
the medium position and toast two slices of bread product
then re-adjust the COLOR CONTROL knob to the desired
setting.
NOTE: To toast moist products such as English muffins, rye
bread, or whole wheat, slow the conveyor by turning the
COlOR CONTROl knob to a darker setting (clockwise).
All TM series toasters can be put into a Power Save mode by
placing the selector switch in the STBY (standby) position. The
toaster is operating at 25% power in the Power Save mode.
NOTE: To place toaster back into full operation, turn the selector
switch to the BREAD or BUN position. Unit is back up
and ready for toasting within 5 minutes.
Always operate toaster with crumb tray installed.
Toasting of coated or buttered products such as garlic
bread, cheese sandwiches, and sweet rolls is NOT
recommended. Residue will reduce toaster performance
and could ignite inside toaster. Using toaster with the food
products listed above will void unit warranty.
7

OPERATION

CAUTION
CAUTION
Selector Switch
