STANDALONE MODE STATIC (Static)
Select the mode "Static" as previously described in STANDALONE MODES and confirm with ENTER. Overall brightness, strobe, amber, cool white
(C White) and warm white (W White) of pixels 1 to 12 can now be configured separately to create an individual scene.
Menu structure
StaAlone ENTER
Static UP/DOWN
ENTER - UP/DOWN
000–255
ENTER - UP/DOWN
000–255
Please refer to the values and descriptions of the stroboscope function as listed in the table below:
Values Description
000–005 Strobe open
006–010 Strobe closed
011–033 Pulse random, slow -> fast
034–056 Ramp up random, slow -> fast
057–079 Ramp down random, slow -> fast
080–102 Random Strobe Effect, slow -> fast
103–127 Strobe Break Effect, 5 s.....1 s (Short burst with break)
128–250 Strobe slow -> fast <1–20 Hz
251–255 Strobe open
SLAVE MODE
Press the MODE button repeatedly until "Menu" is displayed on the top line of the display. Use the UP and DOWN keys to select the menu item
"Slave" and press ENTER. The slave mode is now enabled. Connect the slave and the master units (same model) with a DMX cable and enable
one of the standalone modes on the master unit (Auto, Sound, CCTMacro, TunWhite, Static). Now the slave unit will follow the master unit.
Menu
ENTER
Slave
If you have connected multiple devices, ensure that only one is in standalone mode, that all others are in slave mode, and that there is no DMX
controller connected. Otherwise, control protocols may interfere with each other.
SYSTEM SETTINGS (settings)
Press the MODE button repeatedly until "Menu" is displayed on the top line of the display. Use the UP and DOWN keys to select the menu item
"Settings" and press ENTER. To edit settings, select the desired submenu item with the buttons UP and DOWN and confirm with ENTER (see
tables, note submenus).
8
Static Static
/ /
Intens Strobe
ENTER - UP/DOWN
Intens Strobe
000–255
ENTER ENTER
Pix 1 Pix 1
/ /
Amber C White
ENTER - UP/DOWN
Amber1 C White1
000–255
ENTER ENTER
Pix 1 Pix 12
• • •
W White Amber
ENTER - UP/DOWN ENTER - UP/DOWN
W White1 Amber12
000–255 000–255
ENTER ENTER
Strobe
Pix 12 Pix 12
/ /
C White W White
ENTER - UP/DOWN ENTER - UP/DOWN
CWhite12 WWhite12
000–255 000–255
ENTER ENTER
