A Display
B DOWN button ( )
C MENU button
D UP button ( )
E IR receiver
1 yellow RCA Video 1 input (AV1)
2 yellow RCA Video 2 input (AV2)
3 red RCA Audio input right
4 white RCA Audio input left

6. Installation

The car connection should be carried out by a qualified person only.
• Choose a mounting location, depending on the purpose of the monitor. When used to connect
backing-up or parking camera(s), the driver should have a clear view of the display. For all other
purposes make sure the driver is not distracted by images and/or sound from the system.
• Mount the mounting bracket and attach the monitor to the bracket with the screw or install the
monitor in a headrest using the included frame. When choosing the second option, have the
installation done by a qualified person! The dealer will not accept responsibility for any damage to the
cars interior.
• Connect the monitor jack [8] with the monitor plug [H].
• Connect a camera/video/DVD... (not incl.) to a video input [1][2]. Connect the sound output of that
device to the audio inputs [3][4].
• Make sure the engine is switched off.
• Connect the red +12VDC power cable [5] to the +12VDC power system of the car. Make sure there
is no power on the connection wire (remove fuse).
• Connect the black ground cable [6] to the car ground.
• The monitor can switch on/over to AV2 automatically when reverse gear is selected. To enable this
functionality, connect the blue reverse cable [7] to the reverse gear power circuit. Make sure there
is no power on the connection wire (remove fuse).Connect the backing-up camera to video input
AV2 [2].
• Apply power to the system (re-insert fuses).
Note: the MON10T1 can also be used as a computer/laptop monitor. Connect the computer plug [I] to
the computer using the included cable. When necessary (e.g. no 12Vdc available from car battery),
connect a 12VDC power supply (not incl.) to the power plug on the cable.
7. Use
• Switch on the monitor by pressing the ON/OFF button on the monitor [G] or remote control (
Note that when connection to the reverse gear system is made, the monitor switches on
automatically when reverse gear is selected.
• Select the video channel (AV1, AV2 or VGA) by pressing the video select button on the monitor [F]
or remote control.
Note: select VGA to see images from a connected computer.
• Press the mode select button on the remote control to select the monitor aspect ratio: 16:9 or 4:3.
• Press the menu button [C] on the monitor or remote control to enter monitor setup. Use the menu
button [C] to navigate through the settings; use the up ( ) [D] or down ( ) [B] buttons to change
the settings (on the remote control, use the
Menu option
BRIGHT
CONTRAST
COLOR
MODE
*
IR SELECT
RESET
* Set the same channel on the IR headphone (MONT/HP, not incl.) with the channel selector.
23.09.2011
setting
brightness
contrast
colour
aspect ratio
select IR sound output
reset
MON10T1
F video select button (AV1/AV2)
G power button
H monitor plug
I computer plug
5 red lead
6 black lead
7 blue lead
8 8-pin
resp. buttons).
0 ~ 40
0 ~ 40
0 ~ 40
16:9 or 4:3
IR1 – IR2 - OFF
reset monitor to factory defaults
4
"+" 12Vdc
"-" GND
reverse lamp
monitor jack
value
IR1 = channel A, IR2 = channel B.
