2.7 Taking measurements to wet or shiny surfaces
As long as the range meter can be aimed directly at the surface, the distance to the target will be reliably measured.
With highly reflective surfaces, a reduction in range must be expected and the distance to the actual point of reflection
may be measured.
2.8 Taking measurements to transparent surfaces
It is generally possible to measure distances to transparent or semi-transparent materials, e.g. liquids, polystyrene
foam, etc. Light penetrates these materials, however, and measuring errors may therefore occur. Measuring errors
may also occur when measurements are taken through glass or if objects are present within the line of the laser beam.
2.9 Control panel
"Measure" button
Left arrow button / right arrow button
The "Clear" button has various func-
tions depending on the operating
status:
"Menu" button
On/off button
2.10 The items supplied
1 PD‑E laser range meter
2 Batteries
1 Soft pouch
1 Operating instructions
1 Manufacturer's certificate
1 Hand strap
1 Brochure for users

3 Accessories

Designation
Target plate 1
Target plate 2
Target plate 3
1 With reflective coating (120x130 mm)
2 White (120x130 mm)
3 With reflective coating (210x297 mm)
4 For improved laser beam visibility under difficult lighting conditions.
Quick start (when the tool is switched off, press the button briefly to
switch it on).
Begins distance measurement.
Activates the laser beam.
Activates continuous measuring mode (long press, approx. 2 sec.).
Stops continuous measuring mode.
Confirms the selected function or setting.
Used to navigate between functions and to make settings.
Stops continuous measuring (tracking).
Deletes the last measurement.
Goes one step back (short press).
Deletes all displayed measurements (long press).
Ends the function if no measurements have been taken.
Opens the main menu.
Switches the tool on or off.
Short designation
PDA 50
PDA 51
PDA 52
