English
Configure "My Stuff"
Register an account on http://rotelradio.com website
A personalized menu "My Stuff" can be setup in the top level menu.
Open the website, http://rotelradio.com, from your internet browser.
Please enter the registration key, this can be found in 'Settings > Register'
menu. Enter this registration key into the website and follow the instructions
to setup an user name and password. Remember the user name and
password, you will need this to access the site.
After logging into your account, you will be able to edit your information
for 'My Stations', 'My Streams', 'My Podcast' and 'My Radios'.
Follow the instructions on the website to personalize your menu.
Configure "My Stations"
There are an enormous choice of stations that are available in the
database from the website. Please follow instructions on the website to
search for stations. When search results are displayed, there will be a
link to 'Add to my stations', Click on this and the station selected will be
added to My Stations. A new top level menu 'My Stuff' will appear on
the display, with a sub-menu 'My Stations'.
After the initial registration, you can add to 'My stations' while connected
to a radio station by pressing the REPLY key. The display will ask if you
want to add selection to 'My stations' press the push select knob to add
selection.
Note: You may further organize your stations into FOLDERS (for
instance JAZZ, ROCK, OPERA etc.) These FOLDERS will be displayed
on your Rotel unit.
Configure "My Streams"
While logged into your website account, you can add your own internet
radio streams to the 'My Streams' section which will be listed under 'My
Account'.
Click on 'My Streams', a prompt will appear to enter the station's name
and its media stream URL. The media stream URL should be a link to the
website's actual audio stream. .
Note: 'My Stuff' menu and stations under 'My Stations','My Streams'
will appear after the unit has updated the stations list. Please power
OFF then ON and enter 'Internet Radio' from the top level menu for the
unit to update the stations list.

Remote Unit Advanced Buttons

Setup menu
To enter the setup menu, press the SETUP button on the remote control
and you will see the following display:
1 POWER OPTION
2 DIMMER
3 FACTORY DEFAULT
4 VERSION
5 ANTENNA SELECT
6 EXIT
POWER OPTION. There are two choices for powering up. NORMAL
and QUICK. When option set to NORMAL (Default) the unit consumes
less power during standby mode but takes longer to resume operation
when powered ON. When set to QUICK mode, normal operations are
started immediately after power on (from standby)
DIMMER controls the brightness of the front panel display, it can be
dimmed with seven steps. You can access this control directly with the
DIM button on the remote control.
FACTORY DEFAULT sets the unit into the original state as when it left
the factory. Presets and network configurations will be lost, and sets the
remote code 1 (see below).
VERSION shows this unit's version.
ANTENNA SELECT choose AUTO(default), FM or DAB antenna.
EXIT returns to previous menu.
Second Remote Code
The factory setting is remote code 1. If you find that the remote is
conflicting with other Rotel products, you can change to remote code 2
with the following steps:
1. While pointing the remote at the unit, press on the remote control 'FM'
7
and '2' keys at the same time. Release the 'FM' key and continue
to press the '2' key for 5 seconds. The unit will show 'Audio Custom
Code 1--> 2'.
2. Repeat the above procedure and press '1' key instead of '2' to change
the unit back to Code 1.
3. The unit remote keys, such as PLAY, STOP, PAUSE, use Rotel's standard
codes for CD players. If you find that this is conflicting with your Rotel
CD player, press 'CD' and '2' keys at the same time. Release 'CD' key
and continue to press '2' key for 5 seconds. The display will show 'CD
Custom Code 1 --> 2'.
4. Repeat step 3 above and press '1' key instead of '2' to change the
unit back to Code 1.
15
