Auto Power Off

This setting activates the automatic power off function in the measuring instrument. The moisture meter
switches off when no there has been no measurement or no button pressed within five minutes.
2 sec
1.
22

USB interface

Select the „COM" setting in the menu to enable USB data transfer to a connected PC. It is recommended
to deactivate „Auto Power Off" before transferring data (see Step 21).
2 sec
1.
23
USB data transfer
With the software provided on the CD it is possible to transfer the recorded data to a PC and to use
the data for further processing and documentation. Load the CD in the drive and follow the installation
routine. After successful installation, start the application. Connect one end of the supplied USB cable to
the mini-USB port of the device and the other end to a free USB port on your computer. (Pay attention to
presetting in Step 22!)
For further information on how to use the software, refer to the Help function that contains a detailed
description of the functions.
!
To enable data transfer, pay attention to the presetting described in step 22.
