Resol Solarcheck Prüfbox Anleitung Seite 14

Checkbox
DC Voltage
range resolution
200mV 0.1mV
2V 1mV
20V 10mV
200V 100mV
600V 1V
Input Impendence: 10M�
Overload protection: 250V für 200mV range, effective DC
or AC 600V for other ranges
AC Voltage
range resolution
200V 100mV
600V 1V
Frequency range: 40 - 400Hz
Response: average, calibrated in rms of sine wave
DC Current
range resolution
2mA 1µA
20mA 10µA
200mA 100µA
10A 10mA
Overload protection: F 200mA/250V fuse
Note: 10A range not fused, 200µA range is only for HM-
832L
Resistance
range resolution
200 Ω 0.1 Ω
2K Ω 1 Ω
20K Ω 10 Ω
200K Ω 100 Ω
2M Ω 1K Ω
Overload protection: 250V effective value
Temperatur
range resolution
-30~400 °C 1°C
400~1000 1°C
Overload protection: 250V DC or rms AC
Transistor hFE Test
range resolution
NPN & PNP 0-1000
14
|
accuracy
± (0,5% of rdg + 2 digits)
± (0,5% of rdg + 2 digits)
± (0,5% of rdg + 2 digits)
± (0,8% of rdg + 3 digits)
± (0,8% of rdg + 3 digits)
accuracy
± (1.2% of rdg + 10 digits)
± (1.2% of rdg + 10 digits)
accuracy
± (1.0% of rdg + 2 digits)
± (1.0% of rdg + 2 digits)
± (1.5% of rdg + 12 digits)
± (3.0% of rdg + 2 digits)
accuracy
± (1.2% of rdg + 8 digits)
± (0.8% of rdg + 3 digits)
± (0.8% of rdg + 3 digits)
± (0.8% of rdg + 3 digits)
± (1.2% of rdg + 8 digits)
accuracy
± (1.2% of rdg + 5 digits)
± (2.0% of rdg + 15 digits)
accuracy
ib=10µA/Vce=3V
DiodeTest
range resolution
1mV
Overload protection: 250V effective value
Forward DC current: approximate 1mA
Reversed DC voltage: approximate 3.0V
Continuity
range function
built-in buzzer will sound if resistance is
lower than 50 �
Overload protection: 250V effective value
Forward DC current: approximate 1mA
Reversed DC voltage: approximate 3.0V
Operating Instructions
Before using the multimeter make sure that you have choo-
sen the right function and measurement range.
Measuring DC Voltage
Connect the black test cable to the COM jack and the
red one to „VΩmA" jack. Set the rotary switch on the the
range position. Connect test leads over the source or
working resistance.The value and polarity can now be read
from the LCD Display
NOTE:
When the estimated value is unknown before the measure-
ment set the rotary switch on the highest range.
If only ‚1' or ‚-1' is displayed, it indicates that the measured
value exceeds the measurement range and a higher range
has to be selected.
Attention:
The highest value that can be measured is 600 V. - Higher
voltages may pose a shock hazard.
Measuring AC Voltage
Connect the black test cable to the COM jack and the red
one to „VΩmA" jack. Set the rotary switch on the the desi-
red V~ range position. Connect test leads over the source
or working resistance. The value and polarity can now be
read from the LCD Display
NOTE:
When the estimated value is unknown before the measure-
ment set the rotary switch on the highest range.
If only ‚1' or ‚-1' is displayed, it indicates that the measured
value exceeds the measurement range and a higher range
has to be selected.
function
display: read approximate
forward voltage of diode
