AFRISO CosiTherm D Betriebsanleitung Seite 41

7.3.1 Setting the minimum temperature
A
B
7.3.2 Setting the maximum temperature
Operation
A
B
Room temperature sensor "D"
1. Lift the blue restrictor at
the flag (A).
2. Turn the blue restrictor
with the restrictor adjust-
ment edge (B) to the
desired value for the mini-
mum temperature and
refit it.
1. Lift the red restrictor at the
flag (A).
2. Turn the red restrictor with
the restrictor adjustment
edge (B) to the desired
value for the maximum
temperature and refit it.
3. Turn the cam screw at the
product back to the initial
position so that you can
refit the rotary knob.
4. Refit the rotary knob.
EN
19
