4.3 Dimensions
4.4 Function
CosiTherm® is a single room temperature controller used to control the tem-
perature in rooms with underfloor heating system (heat/cool). The product is
a part of CosiTherm®.
The products measure the actual temperature in the corresponding
rooms.The reference temperature is adjusted via the rotary knob of the prod-
uct.
The product is wired to the controller module.
4.5 Approvals, conformities, certifications
The product complies with:
• EMC Directive (2014/30/EU)
• RoHS Directive (2011/65/EU)
Approvals:
• eu.bac certification as per EN 15500-1:2017
Product description
78 mm
12.5 mm
Room temperature sensor "D"
