Zircon MultiScanner i320 OneStep Bedienungsanleitung

MultiScanner
®
i320 OneStep
™
Multifunction Wall Scanner
The MultiScanner i320 OneStep features three scanning modes:
® ™
• STUD SCAN: Locates the center and edges of wood and metal
studs up to 19 mm deep
• STUD DEEPSCAN ® : Locates the center of wood and metal studs
up to 38 mm deep
• METAL SCAN: Detects and locates ferrous (magnetic) metal
(such as ½ in. rebar) up to 76 mm deep and non-ferrous (non-
magnetic) metal up to 38 mm deep
WireWarning detection automatically detects and alerts of live
®
AC wires in STUD SCAN, STUD DEEPSCAN ® , and METAL SCAN
modes.
1. INSTALLING THE BATTERY
Press battery door release in with your finger or a coin and lift up to remove
door. Connect 9-volt battery to cable. Place into the compartment and press into
place. Replace battery door and snap shut. Battery will last approximately 2 years
under normal conditions.
2. SELECTING THE MODE
Move selector switch to the desired mode: STUD SCAN for finding wood or metal
studs; DEEPSCAN for scanning walls over 19 mm; or METAL SCAN for locating
®
metal.
Unit will remain off if POWER BUTTON is not pressed.
6. WORKING WITH DIFFERENT MATERIALS
Wallpaper: The MultiScanner ® i 320 functions normally on walls covered with
wallpaper or fabric, unless the materials are metallic foil, contain metallic fibers,
or are still wet after application. Wallpaper may need to dry for several weeks
after application.
Freshly painted walls: May take one week or longer to dry after application.
If it is difficult to locate a stud in STUD SCAN mode on fresh paint, switch to
METAL SCAN mode to locate nails or drywall screws holding drywall to studs.
Lath & plaster: Due to irregularities in plaster thickness, it is difficult for the
i
MultiScanner ® 320 to locate studs in STUD SCAN mode. Change to METAL
SCAN mode to locate the nail heads holding wood lath to the studs. If the
plaster has metal mesh reinforcement, MultiScanner i 320 will be unable to
®
detect through that material.
Extremely textured walls or acoustic ceilings: When scanning a ceiling
or wall with an uneven surface, place thin cardboard on the surface to
be scanned and scan over the cardboard in STUD DEEPSCAN mode. If
®
irregular scanning results are received, switch to METAL SCAN mode to
locate nails or drywall screws that line up vertically where a stud or joist is
positioned.
Wood flooring, subflooring, or gypsum drywall over plywood sheathing:
Use DEEPSCAN mode and move the tool slowly. The Signal Strength Indicator
®
may only display 1 or 2 bars when the tool locates a stud through thick surfaces.
MultiScanner i 320 cannot scan for wood studs and joists through carpet and
®
padding. In problematic situations, try using METAL SCAN to locate nails or
screws that may line up vertically where a stud or joist is positioned.
Note: Sensing depth and accuracy can vary due to moisture, content of materials,
wall texture, and paint.
FCC Part 15 Class B Registration Warning
This device complies with Part 15 of FCC Rules. Operations subject to the
following two conditions: (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
SpotLite Signal Strength
®
Pointing System Indicator
LCD Display
WireWarning ®
Detection Indication
Stud Scan Mode Indication
Stud Edge or Center Indication
Middle Bars
ACT ™ (Auto Correcting
Technology) Indication
Metal Mode Indication
Mode Selector Switch
Power Button
Running Board
Battery (back of unit)
7. SCANNING IN METAL MODE
Note: When scanning for studs, use STUD SCAN mode (or Stud DEEPSCAN
Figure A
on thicker walls) to quickly locate the center and edges of wood or metal studs.
Use METAL SCAN to determine if the previous reading in STUD SCAN was a wood
stud, metal stud, or pipe. In METAL SCAN, only metal drywall screws will be found
in wood studs, while metal will be indicated everywhere on a metal stud or pipe.
METAL SCAN has interactive calibration that allows you to adjust its Sensitivity
to metal, which can be used to find the precise location of metal objects in
walls, floors, and ceilings. Maximum sensitivity is ideal for quickly finding the
approximate location of metal. However, sensitivity can be reduced by calibrating
the tool closer to metal. With reduced sensitivity, the area where metal is
indicated will be smaller. But in both cases, the metal target is in the center of
the area where the tool indicates metal is present.
1. Move mode switch to METAL SCAN mode. For maximum metal sensitivity, turn
Figure B
the tool on in the air by pressing and holding the power button. This will ensure
that it calibrates away from any metal objects. (The tool can only be calibrated
off the wall in METAL SCAN mode.)
2. (Figure A) While holding the power button, press the tool flat against The
wall and slowly slide the scanner across the surface. Mark the point where you
get the highest metal indication (the most Middle bars on the screen). If it is a
strong target, the SpotLite
steady beep will sound. Continue in the same direction until display bars reduce.
Reverse direction and mark the spot where the display bars peak from the reversed
direction. The midpoint of the two marks is the location of the center of the metal
object. If the unit indicates metal over a large area, you can refine the scanning
area to more accurately locate the metal target by following steps 3 and 4 below.
3. (Figure B) To further pinpoint the location of the metal target, scan the
Figure C
area again. Release the power button and then turn the unit back on, this time
starting on the wall over one of the previous marks. This will reset the tool to a
lower sensitivity and narrow the scan area.
4. (Figure C) To continue to reduce sensitivity and further refine the scanning
area, repeat step 3. This procedure can be repeated multiple times to narrow the
field even further.
Note: If any bars display on the screen, metal is present. Small targets or targets
deep within the surface may only illuminate some of the bars and not the center
line or audio tone. In this case, use the highest indication to determine the metal
position.
3. FINDING A STUD 4. OPERATING TIPS
Always scan for studs with the scanner placed flat For optimum scanning results, it is important to
against the wall. Move the mode switch to STUD properly hold the MultiScanner
SCAN, place the tool flat against the wall, then press when scanning. The following tips will provide more
and hold the Power button. Wait for beep to confirm accurate scanning results:
calibration has completed before moving scanner.
• Grasp the handle with your thumb on one side
and your fingers on the other side. Make sure your
Slowly slide tool fingertips are resting on or above the running board
across surface. EDGE and not touching the surface being scanned or the
display will illuminate, scanning head of the tool.
indicating location of
• Hold the tool straight up and down, parallel to the
the stud edge.
studs, and do not rotate the tool.
• Keep tool flat against the wall and do not rock, tilt,
Continue sliding tool.
or press hard when slowly sliding across the surface
When the center
being scanned.
of a stud is located
• Avoid placing your other hand, or any other part of
with three bars on
your body, on the surface being scanned. This will
the Signal Strength
interfere with the tool's performance.
Indicator, the four
Middle bars, CENTER
WireWarning Detection
®
display, and SpotLite
®
Zircon's WireWarning
Pointing System will
live AC voltage is detected, the AC detection warning indicator will appear in
all illuminate and the
the display. If scanning begins over a live AC wire, the AC indicator will flash
buzzer will sound.
continuously. If this occurs, release the Power button, move the tool over, and
recalibrate in a new location. Once calibration has completed, begin to slide the
In cases of deeper studs
tool in the direction of your initial calibration.
(thicker walls), when
CAUTION: Wires deeper than 51 mm from the surface, in plastic conduit, or behind
the center of the stud
plywood shear wall, or metallic wall covering may not be detected. Metal shielded
is located only two
wires or those in metal conduit will not be detected. Use extreme caution under
bars will show on the
these circumstances or whenever live AC wiring is present.
Signal Strength Indicator
Always turn off power when working near electrical wires.
and only the SpotLite
®
Pointing System and
four Middle bars will
illuminate. If you still
can't locate a stud, try
STUD DEEPSCAN mode.
®
8. HELPFUL HINTS
mode
®
Situation
Detects other objects
besides studs in STUD SCAN
mode. Finds more targets
than there should be.
Difficulty detecting metal.
Image of metal object appears
wider than actual size.
Constant readings of studs
near windows and doors.
You suspect electrical wires,
but do not detect any.
Pointing System will also shine a beam of light and a
®
ACT, CenterVision, DeepScan, MultiScanner, OneStep, SpotLite, WireWarning, and Zircon are registered trademarks or trademarks of Zircon Corporation.
Visit www.zircon.com/support for the most current instructions.
LIMITED 2 YEAR WARRANTY
Zircon Corporation, ("Zircon") warrants this product to be free from defects in materials and workmanship for
two years from the date of purchase. Any in-warranty defective product returned to Zircon*, freight prepaid
with proof of purchase date and $5.00 to cover postage and handling, will be repaired or replaced at Zircon's
option. This warranty is limited to the electronic circuitry and original case of the product and specifically
excludes damage caused by abuse, unreasonable use or neglect. This warranty is in lieu of all other warranties,
express or implied, and no other representations or claims of any nature shall bind or obligate Zircon. Any
implied warranties applicable to this product are limited to the two year period following its purchase. IN NO
EVENT WILL ZIRCON BE LIABLE FOR ANY SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING
FROM POSSESSION, USE OR MALFUNCTION OF THIS PRODUCT.
In accordance with government regulations, you are advised that: (i) some states do not allow limitations on
how long an implied warranty lasts and/or the exclusion or limitation of incidental or consequential damages,
so the above limitations and/or exclusions may not apply to you, and further (ii) this warranty gives you
specific legal rights and you may also have other rights which vary from state to state.
5. CALIBRATING THE TOOL IN
STUD SCAN/STUD DEEPSCAN
i 320 and move slowly
®
MultiScanner
monitors the subsurface environment 10 times per second and automatically
recalibrates,when needed, to successfully find the center of studs in one step.
• Place MultiScanner
in STUD SCAN or STUD DEEPSCAN
• Once powered on, tool will automatically perform all calibrations. The LCD will
display all icons until calibration is complete. Upon completion of calibration,
the SpotLite
will begin continuous measurements. Continue to press power button down
and keep the tool flat against the wall and begin scanning.
Note: It is important to wait for calibration to complete (1–2 seconds) before
moving the scanner.
• ACT (Auto Correcting Technology):
™
During scanning, the tool will
automatically recalibrate itself
when needed. This recalibration
is transparent and no indication
is made. If an arrow icon
detection feature works continuously in all modes. When
®
illuminates, the tool calibrated
near or over a stud and then
moved away. The arrow indicates
the direction of the missed stud.
(See also number 4, OPERATING TIPS)
Probable Cause
• Electrical wiring and metal/plastic pipes may • Scan the area in METAL SCAN mode to determine if metal is present.
be near or touching back surface of wall. • Check for other studs equally spaced to either side (305, 406, or 610 mm apart) or the same stud
at several places directly above or below the first scan area.
• A stud reading would measure approximately 51 mm apart from each edge; anything larger or
smaller is most likely not a stud if not near a door or window.
• Tool calibrated over metal object. • The scanner may have been calibrated over a metal object, reducing sensitivity. Try calibrating in
• Metal targets too deep or small. another location.
• Scan in both horizontal and vertical directions. Metal sensitivity is increased when metal object is
parallel to sensor, located under Zircon logo.
• Metal has greater density than wood. • To reduce sensitivity, recalibrate MultiScanner
(Metal mode only–See Step 7).
• Double and triple studs are usually found around • Detect outer edges so you know where to begin.
doors and windows. Solid headers are above them.
• Wires are shielded by metal conduit, a braided • Try METAL SCAN to see if you can find metal, wire, or metal conduit.
wire layer, or metallic wall covering. • Try turning on switches to outlet.
• Wires deeper than 51 mm from surface might • Try plugging a lamp into outlet and turning on switch.
not be detected.
• Wires may not be live.
Return product freight prepaid with proof of purchase date (dated sales receipt) and $5.00 to cover postage
and handling, to:
UPS SCS C/O ZIRCON RETURNS
Lohstrabe 30a
85445 Schwaig
Munich, Germany
Be sure to include your name and return address. Out of warranty service and repair, where proof of purchase
is not provided, shall be returned with repairs charged C.O.D. Allow 4 to 6 weeks for delivery.
E-mail: info@zircon.com
U.S. Patents 6023159, 6259241, 6989662, 7116091, and 7148703, Canadian Patents 2141553, 2341385,
and Patents Pending, Japanese Patents 3581851, 4152361, and Patent Pending, German Patent 69333884.9,
French Patent 0657032, U.K. Patent 0657032, and E.U. Patents Pending
©2009 Zircon Corporation • P/N 63683 • Rev A 05/09
®
i 320 can be calibrated anywhere on the wall. It provisionally
®
i 320 against the wall before pressing the Power button
®
mode.
®
® Pointing System and buzzer will momentarily activate and the tool
Solution
i 320 over either of first two marks
®
