O P E R A T I N G I N S T R U C T I O N S
Jumbo Thermometer with Clock
Order no. 64 01 92
Intended use
The product is a combination of a thermometer with display of the indoor and outdoor
temperature, a clock with alarm function, a countdown timer and a date display.
Apart form the outdoor sensor, the product may not get wet or damp; the display unit
may only be operated in dry, closed indoor rooms. Contact with moisture must be
avoided at all times. Any other use than the one described above leads to damage to
the product and is additionally tied to risks.
These operating instructions are part of this product. They contain important instruc-
tions on initial operation and handling. Please bear this in mind when passing on the
product to a third party. For this reason, keep these operating instructions for future
reference. All company and product names mentioned in this document are registered
trademarks. All rights reserved.
Features
• Measuring ranges: Indoor temperature:
Exterior temperature: -50°C to +70°C (-50.00°C to 70.00°C)
• Powered by an AA battery
• Display switchable from °C to °F
• MIN/MAX temperature memory
• Clock Display in 12/24 hour Format
• Date display (month and day)
• Countdown timer (max. 99 minutes, 59 seconds)
• Alarm/wake-up Function
• Table installation or wall mount.
Safety instructions and hazard warnings
The warranty lapses in case of damage resulting from failure to
observe these operating instructions. We will not assume any
responsibility for consequential damage! We will also not assume
any responsibility for damage to assets or persons caused by
improper handling or failure to observe the safety instructions. In
such cases the guarantee will lapse.
• For safety and licensing (CE) reasons, unauthorised conversion and/or modifications
to the product are not permitted.
• The product may not be subjected to extreme temperatures, strong vibrations, heavy
mechanical strain, direct sunlight or high degrees of humidity. This may damage the
product.
• The device is not a toy and has no place in the hands of children.
• Do not leave the packaging material lying around carelessly since it constitutes a
danger to children.
• Do not put the product into operation if it is damaged.
• The manufacturer or supplier will assume no responsibility for incorrect displays or
the consequences which arise through an incorrect display.
• Do not use the product in situations in which professional measuring technology is
required.
• The device may not be used for medical purposes.
• The values determined are not suitable for publication.
• The integrated thermometer is only suited for measuring the ambient air tempera-
ture, not for measuring the temperature of liquids etc.
• Avoid using the appliance under unfavourable ambient conditions.
• If questions arise which are not clarified within the course of these operating instruc-
tions, please contact our technical support or another specialist.
Inserting and Replacing the Battery
Make sure that the polarity is correct when inserting the battery (pay
attention to positive and negative pole!).
Keep batteries out of the reach of children. Do not leave the batteries
lying around in the open; there is the risk that they will be swallowed
by children or pets. Mortal danger! If swallowed, consult a doctor
immediately.
Batteries may not be shorted, opened or thrown into fire. Batteries
must not be recharged. (Danger of explosion!)
Only use a new battery of the correct size and the recommended type.
Chemical liquids may leak out of old or spent batteries and damage
the device. Therefore, remove battery from the device if you do not
require it for a longer period (> 1 month).
Leaking or damaged batteries may burn the skin if touched. Under
these circumstances, protect your hands with suitable gloves.
www.conrad.com
Version 07/06
°
-10°C to +50°C (14°F to 122°F)
Fold out the base on the back and pull the battery compartment cover downwards in the
direction of the arrow. A battery is already inserted. To prevent discharging, there is a
plastic strip between the battery and the battery contact. Pull out the protective strips.
A beep sounds and the display appears. Close the battery compartment again.
The batteries should be replaced if the display contrast has decreased or gone out
completely.
Saved settings are lost when changing the batteries.
Proceed as follows to replace the battery:
Fold out the base on the back and pull the battery compartment cover downwards
in the direction of the arrow. Remove the spent battery and insert an AA battery into
the battery compartment paying attention to the correct polarity (pay attention to
plus and minus!). Close the battery compartment.
Only use a high-quality battery to achieve as long a period of operation as
possible. The use of an accumulator is not recommended because the
operating time is strongly reduced by the low accumulator voltage and
capacity.
Table installation or wall mounting
• There is a fold-out base on the back for table installation. Place the device on a lev-
el and horizontal surface.
• For wall mounting, e.g. on a hook or screw, there is an opening on the back (top).
Pay attention when mounting that no power, gas or water pipes are damaged
by mistake! Mortal danger! The device must be securely attached, otherwise
persons may get hurt when it falls down.
Do not install the device too close to heat sources like heaters, ovens, etc.
and avoid direct sunlight. This would falsify the temperature values or
damage the device.
Attaching the outdoor sensor
• The outdoor sensor (the thick end of the cable with the metal cap) serves for out-
door installation. Install the outdoor sensor outdoors.
• Position it in such a way that it is not directly exposed to sunlight, otherwise the air
temperature is not measured correctly.
• The sensor may not lie in water and rain must be able to drain off. Otherwise the
device does not measure the current air temperature but that of the precipitation,
which leads to false measuring values.
Display
The top display line shows the time, the date, the alarm time or the countdown timer.
A bell icon appears to the left of the time when the alarm time is activated.
The central display line shows the indoor temperature („IN").
The bottom display line shows the outdoor temperature („OUT").
Initial operation
Before first use, remove the protective foil for protection during transit from the
display.
By briefly pressing the button „MODE", you switch between the time, the calendar,
the alarm function and the countdown timer function.
Setting the time and calendar
The device must be in normal time display, with the colon between the
hours and the minutes flashing.
• Press „MODE" for more than 2 seconds until the display for the 12 („12HR") or
24 hour format („24HR") blinks.
• With the button „SET", you switch between 12 or 24 hour format. With the 12 hour
format, „AM" is displayed in the first half of the day and „PM" in the second half.
• Briefly press „MODE" to confirm your setting and the hour display blinks.
• Set the hours with „SET".
• Briefly press „MODE" to confirm your setting and the minute display blinks.
• Set the minutes with „SET".
• Briefly press „MODE" to confirm your setting and the month display blinks.
• Set the month with „SET".
• Briefly press „MODE" to confirm your setting and the date display blinks.
• Set the date with „SET".
• Briefly press „MODE"; the device leaves setup mode and returns to the normal time
display.
If you keep the button„SET" depressed while setting a value, the values
move faster.
If you do not press a button for some time, the device leaves setup mode,
saves the settings and returns to the normal time display.
