Contents
Symbols used in this manual . . . . . . . . . 12
Technical data . . . . . . . . . . . . . . . . . . . . 12
Overview . . . . . . . . . . . . . . . . . . . . . . . . 13
Important safety information . . . . . . . . . 14
Noise and vibration . . . . . . . . . . . . . . . . 15
Instructions for use . . . . . . . . . . . . . . . . 16
Maintenance and care . . . . . . . . . . . . . . 20
Disposal information . . . . . . . . . . . . . . . 20
conformity . . . . . . . . . . . . . . . . . . . . 20
Exemption from liability . . . . . . . . . . . . . 20

Symbols used in this manual

WARNING!
Denotes impending danger. Non-
observance of this warning may result in
death or extremely severe injuries.
CAUTION!
Denotes a potentially dangerous situation.
Non-observance of this warning may result
in injury or damage to property.
NOTE!
Denotes application tips and important
information.

Symbols on the power tool

Before switching on the power
tool, read the operating manual!
Wear protective goggles!
Wear ear defenders!
Use lightweight breathing
protection!
Disposal information for the old
machine (see page 20)!
12

Technical data

Rechargeable
hammer drill
Nominal voltage
Battery
No-load speed
No-load impact rate
Max. single impact
energy (according to
"EPTA procedure
05/2009")
Lubrication
Tool holder
Max. drill diameter
- concrete
- wood
- metal
Weight according to
"EPTA Procedure
01/2003" (without
battery)
Weight of battery 2.5 Ah
Weight of battery 5.0 Ah
CHE 18.0 - EC
CHE 18.0 - EC
V 18
AP 18.0 (2.5 Ah)
AP 18.0 (5.0 Ah)
rpm 0-1400
bpm 0-4500
J 1.7
Grease
SDS-plus
mm 18
mm 20
mm 13
kg 2.0
kg 0.42
kg 0.72
