17. Loop Out – Press this pad to set the end of a loop when in Looping Mode. After a Loop Out point is
set, press this pad again to exit out of the loop. Pressing Shift + Loop Out will set the current pad
mode to "Sample (S)" Mode. See the Pad Mode Commands section for information on this pad's
additional functions.
18. Reloop – Recalls the last set loop. When inside a loop, press this pad to turn the loop off. If a loop has
not been set, this button will create a loop from the start of the song or where Loop In was pressed.
Pressing Shift + Reloop will set the current pad mode to "Hot Cue Mode". See the Pad Mode
Commands section for information on this pad's additional functions.
19. Loop x1/2 – Press this pad to reduce the currently playing loop length by half when in Looping Mode. If
a loop is not playing, this will set the autoloop length. Press Shift + Loop 1/2 to double the loop length.
See the Pad Mode Commands section for information on this pad's additional functions.
20. FX1 On/Off – Turns FX1 on and off per deck. When in Slip Mode this pad will perform a momentary
1/16 beat loop roll. Press Shift + FX1 to set and start playback of a 1-beat autoloop.
21. FX2 On/Off – Turns FX2 on and off per deck. When in Slip Mode this pad will perform a momentary
1/8 beat loop roll. Press Shift + FX2 to set and start playback of a 2-beat autoloop.
22. FX3 On/Off – Turns FX3 on and off per deck. When in Slip Mode this pad will perform a momentary
1/4 beat loop roll. Press Shift + FX3 to set and start playback of a 4-beat autoloop.
23. Filter Reset – Press this pad to reset the filter to the "0" position. When in Slip Mode this pad will
perform a momentary 1/2 loop roll. Press Shift + Filter Reset to set and start playback of a 16-beat
autoloop.
24. Channel Volume – Adjusts the volume of the individual channels in the software.
25. Master Volume – Adjusts the volume of the master mix coming from the software.
Note: This does not affect the microphone volume. Use the Mic Gain knob to control the microphone
volume.
26. Crossfader – Controls the blend between two decks.
27. High EQ – Controls the treble frequencies for the individual channels.
28. Mid EQ – Controls the mid-range frequencies for the individual channels.
29. Low EQ – Controls the bass frequencies for the individual channels.
30. Cue Gain – Adjusts the volume for headphone cueing in the software.
31. Cue Mix – Adjusts the software's audio output to the headphones, mixing between the cue output and
the master mix output.
32. Stutter – Press this button while the music is playing to jump back to the last set cue point, creating a
"stutter" effect.
COMBINATION KEYS
Shift + Pitch Bend - = Activates or deactivates Keylock, allowing you to change the tempo of the track
without changing the original key of the song (0% pitch).
Shift + Pitch Bend + = Adjusts the range of the pitch fader in the software.
Shift + FX Control = Selects the effect.
Shift + FX1 = Sets and starts playback of a 1-beat autoloop.
Shift + FX2 = Sets and starts playback of a 2-beat autoloop.
Shift + FX3 = Sets and starts playback of a 4-beat autoloop.
Shift + Filter Reset = Sets and starts playback of a 16-beat autoloop.
Shift + Layer = Activates Color Selection Mode.
Shift + Scratch Button = Activates Slip Mode. When in Slip Mode, if you scratch, trigger cue points, or
activate loops, the playback marker will jump to where you would be if you had not affected the track.
5
