Cover
8
The cover slides open when push to the
left.
[VIDEO/DC] Iris Selector Switch
9
This should be set according to the type
of lens if an automatic iris control lens is
used.
VIDEO: In case of lens with EE amp built-
in.
DC: In case of lens without EE amp
built-in.
(VIDEO: At time of factory shipment)
[IRIS] Iris Terminal
10
This is connected to an automatic iris
control lens.
( Page 15)
[MENU] Menu Button
11
When pressed, a menu screen is brought
up.
( Page 23)
SET
CAMERA
SETUP
EXT TERM-OFF
AWC
MENU
DUPLEX
RX TERM-OFF
NOT USED
VIDEO
ON
LL
INT/GL
SIMPLEX
ON
IRIS
DC
[SET/AWC] Set. Auto White Control
12
Button
SET: Press this button to display a sub-
menu.
( Page 23)
AWC: If this button is kept pressed for
more than 1 second, a one-push-
auto-white-balance function works
and sets the white balance. Once
it is set, even if colour temperature
changes, white balance does not
change. It is also possible to make
fine adjustments on the set white
balance.
( Page 22)
E-9
