1. Description

Thank you for purchasing this 1-Port RS422/485 Serial PCI-Express Card. It is a uni-
versal add on card that connects to a PC or server via the PCIe Bus, providing high-
speed serial connectivity. The serial ports are fully compatible with RS422/485 stand-
ard by the bundled Serial COM port drivers. It can be set at any mode (RS485 2-wire,
RS485 4-wire and RS422) for different type connections.
Feature:
•
Fully Compliant with PCI Express Base Specifications, Revision 1.1
•
128-byte On-Chip FIFO and Arbitrary Trigger Levels and Interrupts, Automatic
Hardware/Software Flow Control
•
Up to 921.6Kbps Baud Rate
•
Supports 5,6,7,8,9-bits Data Framing
•
Supports 1, 1.5, 2 Stop Bits
•
Support Echo Mode
•
15KV ESD Surge Protection and 2500Vrms Optical Isolation Protection
(only for EX-45352IS)
•
Support Win98, ME, 2000, XP(32/64bit),Vista(32/64bit), Win7(32/64bit)
WinCE and Linux

2. Packet Content

Before you install the RS-422/485 PCIe card in your PC, check the contents of delivery:
•
1 x RS-422/485 Serial PCI card
•
1 x Octopus cable with 2 x 9 pin male connector
•
1 x LowProfile bracket for small computer case
•
1 x Driver CD
•
1 x User Manual
•
Optional 5 Pin Terminal Block (EX-47999)
