Laserworld Diode Series Bedienungsanleitung Seite 9

Manual: Diode Series
Channel
5 Y-axis movement
6 Zoom
7 Y-axis rotation
8 X-axis rotation
9 Z-axis rotation
10 Blanking
11 Sinus movement
12 Color
page 9 / 36
Value
255
0
1 - 167
168 - 188
189 - 209
210 - 254
255
0 - 8
9 -103
104 - 154
155 - 205
206 -255
0
1 - 150
151 - 255
0
1 - 150
151 - 255
0
1 - 180
181 - 217
218 - 255
0 - 70
71 - 140
141 - 209
210 - 255
0
1 - 127
128 - 191
192 - 255
0 - 19
20 - 39
40 - 59
60 - 79
80 - 99
Function
no movement
no movement
manual positioning
movement top to bottom (slow to fast)
movement bottom to top
movement top to bottom
no movement
no zoom
manual zoom (small to big)
small to big (increasing speed)
big to small (increasing speed)
big <--> small (increasing speed)
no rotation
manual positioning
rotation (increasing speed)
no rotation
manual positioning
rotation (increasing speed)
no rotation
Manual positioning
Rotation clockwise (increasing speed)
Rotation anti-clockwise (increasing speed)
No blanking
Dot visibility (fast to slow)
dashed lines
point selection
no movement
manual positioning
left to right (fast to slow)
right to left (fast to slow)
white
red
green
blue
yellow
