Manual: Diode Series
Channel
Please note that not each pattern can be combined with each effect.
• ILDA control:
Connect your device („ILDA IN") via an ILDA cable to an interface / controller. ILDA mode
starts immediately. Use a laser control software, e.g. Laserworld Showeditor, to run the
device. Use „ILDA OUT" to connect it to another device.
• Master-Slave-Mode:
To use the daisy chain / Master-Slave-Mode connect two (or more) laser projectors of
the same series via DMX cables:
Master projector (DMX out) -> DMX cable -> slave projector 1 (DMX in) ;
slave projector 1 (DMX out) -> DMX cable -> slave projector 2 ...etc.
Master projector
Select auto or
music mode at the
master projector
(see above)
• Timer
This device has an integrated timer. Press the MODE button until the displays shows the
timer. Press DIR to confirm.
• Animations
Select this mode by pressing the MODE button until the display shows Auoo and con-
firm by pressing DIR. Now the laser device projects animations in random order
10. To turn off the device switch it off („OFF"), turn the key ‚OFF' and disconnect the power
cable from the mains.
Convergence settings for dichros - Service openings
Settings for convergence must be made while the laser unit is running, therefore please take
care about your safety first - Don't look directly at the laser beam!
page 10 / 36
Value
100 - 119
120 - 138
139 - 164
165 - 248
249 - 254
255
DMX cable
Function
purple
cyan
multi-color
changing multi-color (fast to slow)
changing multi-color 2
multi-color 2
Slave projector
To use this mode, please press
the MODE button until the dis-
play shows SLAV and confirm
by pressing DIR.
