Manual: Diode Series
1. There is a flap on the front panel. Unscrew the screws and carefully remove the flap.
Both dichros are right behind the flap.
2. Now you can set the color convergence using the two dichros, by carefully adjusting the
allen screws.
3. With the correct setting of the color balance ( put red, green and blue on top) you get a
perfect white.
4. After setting up, cautiously attach the flap back on the front panel of the laser unit.
Important Note:
Operate scanners/galvos only at appropriate speed according to the res-
pective scan angle. Too high scan speed will damage the scanning system.
