Ransomes Highway 2130 Wartung Und Service Seite 105

12b SEAT GRAMMER MSG 85 SEAT (4137966) - SEAT TOP
ITEM PART NO
1
2
3
4
5
7
8
22
23
24
25
26 113048
27
28
29
33
34
35
36
37
38
39
40
42
44
46
48
49
54
67
68
69
88
89
DESCRIPTION
Assy, Cushion, Backrest
Assy, Cushion, Seat
Screw, M5 x 25, Pan Hd
Seat Pan
Backrest Pan Kit
Tube
Backrest Extension
Tube
Screw, M8-1.25 x 40
Rivet, 6 x 12
Nut, Hex, M8-1.25
Nut, Hex, M8-1.25
Lever
Handle, Grey
Cover, LH, Blk
Cover, RH, Blk
Screw M8 x 16
Set of Adjustment Rails
Nut, Hex M8-1.25
Washer, Flat, M8
Washer 8.4-Hv140
Kit, Seatbelt, 2 Retractable
Seatbelt, 2 Non-retractable
Spring, Spiral
Stop
Bearing Kit
Spring, Leg, Backrest
Set of Adjustment Rails
Screw, M8 x 16, Hex Socket
Literature Box
Blind Rivet 3.2 x 11.2
Ball
Armrest
Armrest
* Not Illustrated
RANSOMES HIGHWAY 2130
MAINTENANCE AND PARTS MANUAL
QTY REMARKS
1
1
7
1
1
2
1
2
2
1
6
2
1
1
1
1
4
1
4
11
6
1
1
1
1
1
1
1
4
1
5
5
1
1
N/A Not Available
LIST OF PARTS
