Dismantling / Assembly (see Fig. 2 - 5)
1. Follow the safety measures. Disconnect the pump!
2. Push the two flaps at the front side of the pump inwards. Lift and remove upper shell (1).
3. Remove the entire pump (7) with pump housing (4) from the lower shell (2).
4. Loosen the 4 screws (9).
5. Unclip pump housing (4) from motor housing (4).
6. Remove rotor assembly (5) from motor housing (7). Pay attention to the O-ring (6) in the motor
housing (7).
7. Clean all parts using clear water and soft sponge.
8. Mounting:
- Press the O-ring (6) onto the rim in the motor housing (7).
- Push the rotor assembly (5) onto the motor housing (7) with precaution and turn the bearing cap so
that the two holes fit on the pins in the motor housing (7).
- Make sure the rotor assembly is free and will turn.
- Check the position of the O-ring (6) in the motor housing (7).
- Plug the pump housing (4) in the motor housing (7) and tighten the 4 screws (9) uniformly.
9. Place the pump (7) in the lower tray (2) in this process pay attention to the three rubber supports (8+9).
10. Attach the upper shell (1) to the rear hook of the lower shell (2) and lock it into the front flaps.
Maintenance
In order to prolong the service life of your pump significantly and to keep it in sound operating condition, it is
recommended to carry out maintenance and cleanup regularly.
This can be done by everyone, quickly and easily. See „Dismantling/Assembly"
Servicing intervals
- In the beginning check proper performance of your pump every day. If necessary, clean the filters.
- Since servicing intervals (complete cleaning) will vary depending on the level of pond pollution, repeat the
periodic service to your pump in accordance with the pollution of the pond water .
Should you determine that there are damaged or worn parts, replace them. See „Spare parts"
Important! When used in calcareous water, the rotor assembly (15) and the stainless steel can split
tube in the motor housing (10) should be cleaned at regular intervals.
Pump care in wintertime
Protect your pump from freezing-up!
Take the pump out of your pond in autumn. Clean the pump completely according to the instructions.
During the winter months store the pump in a tank filled with water to prevent the bearings from drying out.
Store the tank in a frostproof room.
Spare parts
To order spare parts, please indicate the pump type, the designation and the Art.-No. from the table below
(see also fig. 5).
Item Designation
1 Upper shell
2 Lower shell
3 Handle
4 Pump housing G 1¼" - OT
Pump housing G 1½" - OT
5 Rotor
Rotor
6 O-ring 96 x 3
8 Rubber lagging C3
9 Rubber lagging F3
10 Screw M 6 x 16
11 Stainless steel screen F3
12 Plastic screen F3
13 Regulator sheath G 1¼" - IT
14 Regulator sheath G 1½" - IT
15 Control knob F3
16 Socket G 1¼" - IT
Socket G 1½" - IT
17 Angle G 1¼" - IT
Angle G 1½" - IT
18 Hose adapter
G 1¼" - OT - Ø 40 / 32 / 25
Hose adapter
G 1½" - OT - Ø 50 / 40
19 Clip
Pump Type
Flow Pro 6500
Flow Pro 16000
Flow Pro 6500, Flow Pro 16000
Flow Pro 6500, Flow Pro 16000
Flow Pro 6500
Flow Pro 16000
Flow Pro 6500
Flow Pro 16000
Flow Pro 6500, Flow Pro 16000
Flow Pro 6500, Flow Pro 16000
Flow Pro 6500, Flow Pro 16000
Flow Pro 6500, Flow Pro 16000
Flow Pro 6500, Flow Pro 16000
Flow Pro 6500, Flow Pro 16000
Flow Pro 6500
Flow Pro 16000
Flow Pro 6500, Flow Pro 16000
Flow Pro 6500
Flow Pro 16000
Flow Pro 6500
Flow Pro 16000
Flow Pro 6500
Flow Pro 16000
Flow Pro 6500, Flow Pro 16000
10
Art-No.
104/004076
104/004080
104/004075
104/004079
104/003559
104/003558
168/009141
168/009144
112/000030
104/003452
104/004074
114/000048
104/004077
104/004145
104/004095
104/004094
104/004096
104/002641
104/001967
104/003711
104/003715
104/003042
104/003424
104/004163
