Reloop RMP-2 MK2 Bedienungsanleitung Seite 34

40.6.3mm headphones connection
41. Volume control for headphones
42.Voltage switch
ATTENTION!
Damage caused by independently switching to the wrong voltage leads to a
waiver of any guarantee or warranty claims.
43. Cinch output hub
44.Digital output hub
45. On/Off Switch
46.Line cord connection hub
SAMPLING
This chapter details the possibilities and settings of the mighty on-board sampler
of your device.
A loop is the permanent repetition of a sequence between a chosen loop starting
point and a chosen loop end point. Select a loop starting point by pressing the
Loop IN button -12-. Select the Loop End point by pressing the Loop OUT button
-13-. The player goes automatically into Loop mode and the Reloop display
flashes. The sequence thus chosen is seamlessly re-played until the Loop OUT
button - 13- is pressed a second time. The player seamlessly goes into Play mode.
To prompt the last played loop against, press the Reloop button -14-. The player
goes automatically into Loop mode.
NOTES:
•
•
You have four sample banks available, each of 5 seconds. To record a sample, set
a loop as described above using the Loop IN and Loop OUT buttons. Then press
the Memory button -16- and then one of the four memory buttons -15- The loop
thus set is now saved in the chosen sample bank and the Memory button goes
off. To play a sample, first press the Sampler button -17-. Then press the desired
one of the four memory buttons. The Sampler plays the sample from the chosen
bank in an endless loop (Endless mode). Press the Sample button once again to
play the sample once only (One Shot mode). To end playing the sample, press the
Sample button again. The light goes off.
34
Attach to this output -40- headphones with a 6.3 mm jack cable for
monitoring.
Use the wheel -41- to adjust the volume of the headphones.
Switch to select the correct voltage of your country, either 115V or 230V.
Connect the output hubs -43- with the Line IN hubs of your mixing console
or amplifier.
Connect the digital output hub -44- to a device that features a digital input,
for example a CD burner, MD recorder, digital mixer or audio card.
Switch your device on or off with this switch.
Connect the connection hub -46- with a line cord and insert it into an outlet.
The player saves this loop for the current track only. When changing to
a different track, no loop is stored.
The currently saved Loop starting point (set with the Loop IN
button -12-) is also the current Cue Point. When saving a new Cue Point,
after saving a Loop and exiting the Loop mode, this overwrites the
current starting point. The re-loop display goes off and no loop is saved
anymore.
