Dear MAGNAT Customer,
The PANTERA TWO car hi-fi power amplifier will enable you to satisfy your high demands on sound reproduction
in your car. With its impressive deep-bass power reserves, low harmonic content and neutral reproduction, the
PANTERA TWO takes car hi-fi to new heights. The amplifier is characterized by low operating current, rapid
switching capabilities and excellent temperature stability. Increased output power can be achieved by switching
two amplifier channels in an amplifier together in bridging mode. Experience and enjoy how this high-tech
machine perfectly reproduces magnificent sound.
MAGNAT Audio-Produkte GmbH
Please read all of the owner's manual before installing and using the amplifier.
1.

TECHNICAL DATA

Max. output power (1 kHz sinus burst 2:8, B+=14.4V)
Nominal output power (DIN 45 342, B+=14.4V)
Max. output power (1 kHz sinus burst 2:8, B+=14.4V)
Nominal output power (DIN 45 342, B+=14.4V)
Loudspeaker impedance (stereo mode)
Frequency response
Total harmonic content (DIN 45 403)
Stereo separation (IEC 581 )
Weighted noise distance (IEC A)
Input sensitivity LOW LEVEL INPUT
Input impedance LOW LEVEL INPUT
Low-pass filter
High-pass filter
Bass boost
Supply
Fuse
Sizes (W x H x D)
Weight
SUBJECT TO TECHNICAL CHANGE
2. FEATURES
•
Complementary push-pull final stage
•
Stable at 2 ohms
•
Infinitely adjustable high-pass and low-pass filters
•
Infinitely variable bass equalisation
•
Bridgeable 2-/1-channel mode
•
Electronic protective circuit against short circuiting, DC offset and excess temperature
•
Mute switch for suppressing switch-on crackle interference
•
Capsulated loudspeaker and power-supply screw terminals
•
Status indicator (green LED) and overload indicator (red LED)
GB
PANTERA TWO
Stereo / Bridged
2 x 225 W / 1 x 700 W
2 x 100 W / 1 x 300 W
2 x 350 W
2 x 150 W
2 – 8 Ohm
5 – 90 000 Hz (-3 dB)
< 0.03% (1 kHz)
> 65 dB (1 kHz)
> 105 dB
0.4 – 4 V
47 kOhm
40 – 250 Hz, 12 dB per octave
40 – 250 Hz, 12 dB per octave
0 – 12 dB at 45 Hz
+ 12 V (10 – 15 V), minus to ground
1 x 30 A
365 x 65 x 280 mm
4.4 kg
8
on 4 Ohm
on 4 Ohm
on 2 Ohm
on 2 Ohm
