FIG. 1 POWER SUPPLY / REMOTE SWITCH-ON CONNECTION
(1) GND terminal for the ground, to the battery's minus pole
(2) REM terminal for remote switch-on
(3) Terminal for + 12 V battery voltage
(4) Battery
(5) Cable fuse
(6) To your car radio's automatic aerial connection
If your car is not equipped with an automatic aerial connection, connect this cable's plus pole (+) to the
ignition lock. An on/off switch should be inserted in this case. Make sure that this switch is switched off if
the amplifier is not used.
FIG. 2 STEREO MODE
Connect and set the amplifier as shown in Fig. 2 if it is to be controlled with two output channels and to use two
loudspeakers. The high-pass filter must also be activated if the amplifier is also used for satellite loudspeakers.
See Chapter 5.3.
(1) To the car radio, left output
(2) To the car radio, right output
(3) Loudspeaker left
(4) Loudspeaker right
FIG. 3 BRIDGE MODE WITH STEREO CAR RADIO
If the amplifier has to generate more power to operate a subwoofer, connect and set it as shown in Fig. 3. The
use of the low-pass filter is described in Chapter 5.2.
(1) To the car radio, left output
(2) To the car radio, right output
(3) Subwoofer
FIG. 4 MONO MODE WITH ONE CAR RADIO WITH SUBWOOFER OUTPUT
(1) To the car radio, subwoofer output
(2) Subwoofer
(3) Audio Cable
FIG. 5 OPERATING ELEMENTS
(1) Bass-booster control
(2) Low pass filter (LPF) / linear (FULL) / high pass filter (HPF) option switch
(3) Cross-over frequency control for the low pass
(4) Cross-over frequency control for the high pass
(5) Input level control
