DMX Protocol

3. channel mode
Control-channel 1 - Dimmer
Decimal Hexad. Percentage S/F
0 255 00 FF 0% 100%
Control-channel 2 - Strobe
Decimal Hexad. Percentage S/F
0 5 00 05 0% 2%
6 20 06 14 2% 8%
21 60 15 3C 8% 24%
61 100 3D 64 24% 39%
101 140 65 8C 40% 55%
141 180 8D B4 55% 71%
181 220 B5 DC 71% 86%
221 255 DD FF 87% 100%
Control-channel 5 - Color-change linear
Decimal Hexad. Percentage S/F
0 10 00 0A 0% 4%
11 11 0B 0B 4% 4%
12 50 0C 32 5% 20%
51 51 33 33 20% 20%
52 90 34 5A 20% 35%
91 91 5B 5B 36% 36%
92 130 5C 82 36% 51%
131 131 83 83 51% 51%
132 170 84 AA 52% 67%
171 171 AB AB 67% 67%
172 210 AC D2 67% 82%
211 211 D3 D3 83% 83%
212 250 D4 FA 83% 98%
251 255 FB FF 98% 100%
3 channel mode
Control-channel 1 - Red
Decimal Hexad. Percentage S/F
0 255 00 FF 0% 100%
Control-channel 2 - Green
Decimal Hexad. Percentage S/F
0 255 00 FF 0% 100%
Control-channel 3 - Blue
Decimal Hexad. Percentage S/F
0 255 00 FF 0% 100%
F Gradual adjustment of the dimmer intensity from 0 to 100 %
S No function
F Strobe effect (asynchron) with increasing speed
F Strobe effect (synchron) with increasing speed
F Strobe effect (sinus wave) with increasing speed
F Random strobe effect with increasing speed
F Opening pulse effect with increasing speed
F Closing pulse effect with increasing speed
F Strobe effect (square wave) with increasing speed
S No function
S Blue
F Red 0% / green increasing / blue 100%
S Cyan
F Red 0% / green 100% / blue decreasing
S Green
F Red increasing / green 100% / blue 0%
S Yellow
F Red 100% / green decreasing / blue 0%
S Red
F Red 100% / green 0% / blue increasing
S Magenta
F Red decreasing / green 0% / blue 100%
S Blue
F Red (0=off, 255=100% red)
F Green (0=off, 255=100% green)
F Blue (0=off, 255=100% blue)
30/36
Feature
Feature
Feature
Feature
Feature
Feature
00101912, Version 1.0
