Controls

OSM™ (On-Screen Manager) control buttons on the front of the
monitor function as follows:
To access OSM menu, press any of the control buttons (
To change signal input, press the INPUT 1/2 button.
EXIT
CONTROL /
CONTROL /
PROCEED
RESET
NOTE: When RESET is pressed in the main and sub-menu, a warning window will appear
allowing you to cancel the RESET function by pressing the EXIT button.
Brightness/Contrast Controls
BRIGHTNESS
Adjusts the overall image and background screen brightness.
CONTRAST
Adjusts the image brightness in relation to the background.
AUTO ADJUST
Adjusts the image displayed for non-standard video inputs.
Auto Adjust
Automatically adjusts the Image Position and H. Size settings and Fine settings.
Position Controls
LEFT / RIGHT
Controls Horizontal Image Position within the display area of the LCD.
DOWN / UP
Controls Vertical Image Position within the display area of the LCD.
AUTO ADJUST
Automatically sets the Horizontal and Vertical Image Position within the
display area of the LCD.
LCD1830.wpc
Main Menu
Exits the OSM controls.
Moves the highlighted
area up/down to select
one of the controls.
Moves the highlighted area
left/right to select control
menus.
Has no function
Push PROCEED to activate
Auto Adjust.
Resets the highlighted
control menu to the factory
setting.
7
9
, , , ).
Sub-Menu
Exits to the OSM main
menu.
Moves the highlighted
area up/down to select
one of the controls.
Moves the bar left/
right to increase or
decrease the adjustment.
Activates Auto Adjust feature.
In Tools and Information
Mode, opens additional
window.
Resets the highlighted
control to the factory
setting.
