NEC MultiSync LCD1830 Benutzerhandbuch Seite 6

Quick Start
AC Power
Cord
Signal
Cable
1. Cables pass through in this hole.
2. Connect each connector
3. Replace connector cover with cables
passing through upper opening.
Power Outlet
LCD1830.wpc
–continued
Figure C.1
To Computer
Power Switch
Figure D.1
4
6
AC-IN
INPUT2
INPUT1
