Technical data

DVISplitter2
Resolution:
Supported
video data
Colour depth:
Video input:
Video outputs:
DDC:
between graphics card and splitter:
Cable lengths*
between splitters:
Number of cascade levels
Cascading*
Type:
Power supply
Connection:
Power input:
Standby:
Power input
Operation:
Material:
Casing
Dimensions (W x H x D):
Weight:
Temperature:
Operation envi-
ronment
Air humidity:
Conformity
*Note: All cable lengths and numbers of cascade levels depend on the applied gra-
phics card.
The tested graphics cards showed major differences regarding the quality of
the graphic cards' video signals and the hence resulting cable lengths and
cascade levels.
The stated data are based on empirical values that were achieved by the
majority of the tested graphics cards.
Technical data
max. 1920 x 1200 @ 60 Hz
24 Bit
1 x DVI-D (single link)
2 x DVI-D (single link)
DDC information at DVI Out 1 inter-
face
50 metres
50 metres
3
power pack(12V/2A)
Mini-DIN 4 socket
12VDC
0,96W@12VDC
3,12W@12VDC
anodised aluminium
105 x 26 x 84 mm
approx. 210 g
+5 to +40 °C
< 80%, non-condensing
CE, RoHs
G&D DVISplitter2 · 6
