L
S1
S2
N
N
Load
t
Last (Heizung)
Load (Heating)
Sensor
Charge (chauffage)
Sensor
Capteur
THERMOSTAT INSTALLATION BEI MEHREREN HEIZMATTEN
THERMOSTAT INSTALLATION FOR TWO OR MORE HEATING MATS
INSTALLATION DU THERMOSTAT POUR PLUSIEURS NATTES CHAUFFANTES
4
4
230 VAC
3
Electrical box
for two or more
heating mats
(30 cm height)
3
Prise à 30 cm
du sol au cas où
il y a plusieurs
nattes chauffantes
5
Installationsplan
1 Elektronisches Thermostat,
Zuleitung NYM 3 x 1,5 mm² zur
Verteilung
2 Wellrohr für Temperaturfühler
(Bodenfühler) oder Kaltleiter.
Beide dürfen nicht zusammen in einem
Rohr verlegt werden
3 Unterputzdose (bei mehreren Heizmatten,
die zu einem
Thermostat
separate Unterputzdose
Installations drawing
1
Electronic t
power supply distribution cable
NYM 3 x 1,5 mm²
2
Corrugated tubes for the temperature
sensor and the cold lead.(Both are not
to
be installed inside the same tube)
3
Recessed electrical box (only necessary
for two or more heating mats to one
thermostat).
Plan d'installation
1
Thermostat électronique, Câble
d'alimentation NYM 3 x 1,5 mm² pour la
répartition.
2
Tube ondulé pour le capteur (de sol) ou
pour le conducteur froid. Il ne faut pas
les poser dans le même tube.
3
Prise encastrée (si plusieurs nattes
chauffantes sont reliées au même
thermostat, une prise encastrée
séparée est requise).
führen, ist eine
erforderlich
)
hermostat,
