Parts List
Part
Description
No.
1
Boatstand, front support
2
Boatstand, rear support
3
Boatstand, side piece
4
Rudder system reinforcement, top
5
Rudder system reinforcement, side
6
Rudder system reinforcement, front
7
Rudder bush
8
Hull
9
Motor mount
10
Motor mount support plate
11
Screw
12
Nut
13
Stern tube
14
SPEED 600 ECO electric motor
15
Suppressor capacitor
16
Copper cable
17
G2 connector
18
Shaft coupling
19
Grubscrew
20
Motor retaining screw
21
Propeller
22
Rudder blade
23
Tiller
24
Collet
25
Retaining screw
26
Rudder servo
27
Rudder servo mount, base plate
28
Rudder servo mount, front panel
29
Rudder servo mount, rear panel
30
Rudder servo mount, side panel
31
Swivel pushrod connector
32
Swivel connector grubscrew
33
Swivel connector retaining nut
34
Rudder pushrod
35
Reinforcing frame, side panel
36
Reinforcing frame, rear panel
37
Reinforcing frame, cross-piece 1
38
Reinforcing frame, cross-piece 2
39
Reinforcing frame, cross-piece 3
40
Reinforcing frame, cross-piece 4
41
Reinforcing frame, cross-piece 5
42
Water pump intake nipple
43
Short water hose
44
Long water hose
45
Water pump
46
Suppressor capacitor
47
Copper cable
48
G2 connector
49
Velcro tape
50
Deck
51
Forward platform, base plate
GRAUPNER GmbH & Co. KG D-73230 KIRCHHEIM/TECK GERMANY
Keine Haftung für Druckfehler. Technische Änderungen vorbehalten! Liability for printing errors excluded. We reserve the right to introduce modifications. Sous réserve de modifications!
Nous ne sommes pas responsables d'éventuelles erreurs d'impression!
No.
Material
off
1
Plywood
1
Plywood
2
Plywood
1
Plywood
2
Plywood
1
Plywood
1
Brass
1
ABS
1
Plastic
1
Plywood
2
Plated brass
2
Plated brass
1
Metal
1
Various
1
Various
2
Various
1
Various
1
Aluminium
4
Blacked steel M3 x 3 mm
2
Blacked steel M3 x 8 mm
1
Various
1
Various
1
Plastic
1
Plated brass
1
Blacked steel M3 x 6 mm
1
Various
1
Plywood
1
Plywood
1
Plywood
1
Plywood
2
Plated brass
2
Blacked steel M3 x 3 mm
2
Plastic
1
Plated steel
2
Plywood
1
Plywood
1
Plywood
1
Plywood
1
Plywood
1
Plywood
1
Plywood
2
Aluminium
1
Silicone
1
Silicone
1
Various
1
Various
2
Various
1
Various
1
Plastic
1
ABS
1
ABS
#0058986
Size and thickness in mm
4 mm, laser-cut
4 mm, laser-cut
4 mm, laser-cut
2 mm, laser-cut
2 mm, laser-cut
2 mm, laser-cut
Tube, 4 / 3.1 Ø x 47 mm
Vacuum-moulded, CNC-trimmed
Ready made
2 mm, laser-cut
M2 x 6 mm
M2
6 / 4 Ø x175 / 186 mm
Order No. 3323
Order No. 3588
Order No. 3389
Order No. 2989
9 Ø x 18 mm
32 mm Ø (as Order No. 2303.32)
Ready made
Ready made
7 / 3 Ø x 4.5 mm
Ready made, from RC set
2 mm, laser-cut
2 mm, laser-cut
2 mm, laser-cut
2 mm, laser-cut
Ready made
M2
2 Ø x 130 mm, overlength
2 mm, laser-cut
2 mm, laser-cut
2 mm, laser-cut
2 mm, laser-cut
2 mm, laser-cut
2 mm, laser-cut
2 mm, laser-cut
4 / 3 Ø x 35 mm, overlength
7 / 3 Ø x 100 mm
7 / 3 Ø x 160 mm
Order No. 914
Order No. 3588
Order No. 3389
Order No. 2989
Cut strips as required
Vacuum-moulded, CNC-trimmed
1.5 mm, laser-cut
25
08/2008
