3.1.6

Temperature measurement

To measure the temperature, proceed as follows :
1. Set the switch to
;
2. to select the temperature unit and scale (° C or
Press
° F) ;
Remark : the default is ° C.
3. Connect the temperature probe adapter (item 1) to the
COM and "+" terminals, observing the polarity;
4. Connect the temperature probe (item 2) to the adapter,
observing the polarity;
Nota : if the probe is disconnected or open-circuit, the display
unit indicates OL.
The thermocouple temperature indication is displayed on
screen.
3.1.7

Current measurement

1. Set the switch to
;
2. Select AC or DC by pressing
is in DC mode. According to your selection, the screen
displays DC or AC ;
3. Connect the black lead to the COM terminal and the red
lead to "10A" ;
4. Connect the multimeter in series in the circuit.
45 - 138
. As default, the device
