English
3 AC or DC voltage measurement (V)
4 AC or DC voltage measurement (mV)
5 Resistance measurement
Continuity test
Diode test
6 Capacitance measurement
7 Temperature measurement in ° C or ° F
8 AC or DC current measurement
9 NVC (Non Contact Voltage) + Partial OFF
mode of the multimeter (NCV function active)

1.4 THE TERMINALS

The terminals are used as follows :
1 2
Figure 5 : the terminals
Item Function
1 Current measurement terminal (10 A)
2 Cold point terminal (COM)
3 Hot point terminal (+)

2. USE

2.1 FIRST USE

Insert the battery provided with the instrument as follows:
39 - 138
3.1.1
3.1.1
3.1.2
3.1.3
3.1.4
3.1.5
3.1.6
3.1.7
3.1.8
3
