1. Using a screwdriver, unscrew the four screws (a, b, c, and
d) holding the cover (item 1) on the back of the housing;
2. Place the battery in its compartment (item 2); watch out
for the polarity;
3. Screw the cover back onto the housing. Put the stand
back in place.
a b
1
c d
Figure 6 : access to the battery

2.2 POWERING UP THE MULTIMETER

The switch is set to
. Turn the switch to the function of your
choice. All segments of the display unit light for a few seconds
(see figure 2, § 1.1) the screen corresponding to the chosen
function then appears. The multimeter is now ready for
measurements.

2.3 POWERING DOWN THE MULTIMETER

The multimeter can be switched off manually, by setting the
switch to
, it will also switch itself off automatically if left
unused for 15 minutes. At the 14th minute, 5 beeps warn that
the multimeter is about to be switched off. To reactivate the
instrument, press any key on the keypad.
Nota : the position does not completely switch off the
multimeter; it remains active for contact-free detection of the
presence of the network voltage (NCV).
