EtherNet/IP

10.2 EtherNet/IP-Parameter

10.2.1 Identity-Objekt

Der Switch unterstützt das Identity Object (Class Code 01) von EtherNet/IP.
Die Hirschmann-Hersteller-ID ist 634. Hirschmann verwendet die hersteller-
spezifische ID 149 (95
Ethernet Switch".
Id Attribute
1 Vendor ID
2 Device Type
3 Product Code
4 Revision
5 Status
6 Serial Number Get
7 Product Name Get
Tab. 32: Identity-Objekt
UM Grundkonfiguration L3P
Release 7.1 12/2011
) zur Kennzeichnung des Produkttyps „Managed
H
Access Data type
Rule
Get UINT
Get UINT
Get UINT
Get STRUCT
USINT Major
USINT Minor
Get WORD
UDINT
Short String
(max. 32 Byte)
10.2 EtherNet/IP-Parameter
Description
Hirschmann 634
Vendor-specific Definition 149 (95H)
"Managed Ethernet Switch".
Product Code: mapping is defined for every
device type, e.g.
RS20-0400T1T1SDAPHH is 16650.
Revision of the Ethernet/IP implementation,
currently 1.1,
Major Revision and Minor Revision
Not used
Serial number of the device (contains last
3 Bytes of MAC address).
Displayed as "Hirschmann" + order code, e.g.
Hirschmann RSxxxxx.
