Do as follows to switch off the gas heating.
1 Press the button with the
arrow until the symbol for
gas heating flashes. The text
"ON" is displayed next to the
temperature on the display.
blinkar
flashes
7. Heating with 230 V electric
The more kW power used the quicker the heat up time. 3kW is not available on all boilers.
1 Press the button with the arrow
until the symbol for electrical
heating flashes.
blinkar
flashes
Do as follows to switch off heating with electricity.
1 Press the button with the arrow
until the symbol for electrical
heating flashes.
blinkar
flashes

8. Circulation pump

This symbol means that the circulation pump is
operating (12V Pump or 230V Pump). When fitted to the
boiler will select the 230 V Pump automatically when
230 V voltage is supplied to the boiler.
9. 230V connection
This symbol is lit up when 230V voltage is connected to
the caravan.
2 Switch off the gas heating by
pressing the -/Off button. The
text "OFF" is displayed next to
the temperature on the display.
blinkar
flashes
2 Select power (1kW, 2kW or 3kW)
by using buttons +/On or -/Off.
The diagram shows that the
3kW has been selected (not all
caravans can select 3kW, some
can only select 1-2kW).
blinkar
flashes
2 Switch off the electrical heating
by pressing the -/Off button until
all power steps have gone out.
GB
3 Press the button to the left
until the control panel reverts
to standby. The symbol for gas
heating is no longer displayed.
3 Press the arrow to the left until
the control panel reverts to
standby. The symbol for electrical
heating is displayed constantly.
3 Press the arrow to the left until
the control panel reverts to
standby. The electrical heating
symbol has now gone out.
7
