Technical Data - Clatronic WC 3528 Window cleaner Bedienungsanleitung

Charging the Battery
1. Connect the cable of the charger to the charging socket (3).
2. Observe the mains voltage! Check whether the voltage of
the charger as indicated on the rating label is suitable for
the mains voltage.
3. Connect the mains adapter to an approved wall socket.
4. The lamp (4) lights up red.
NOTE:
• Charge the battery regularly after use.
• Protect the battery from damage and overload.
• Charging takes approx. 14-16 hours.
• The lamp lights up green when the battery is fully
charged.
5. Then unplug the charger from the wall socket and discon-
nect the cable from the charging socket (3).
Cleaning windows
1. Fill the spray bottle with tap water.
2. Attach the micro fleece cloth to the
Velcro strip.
3. Evenly spray the window with
water.
4. Clean the glass surface with the
micro fleece cloth.
5. Turn the device around and
position the lip in one upper corner
of the window frame.
6. Press the button and pull down
the device with a steady and slow
movement.
7. Dry the complete window surface
that way, while observing the water
level in the tank!
Tips and questions
The windowpane is still wet after sucking one time. What can I
do?
• Spray the pane with less water.
• Empty the water tank if full.
• Is the motor power strong enough? If not, charge the bat-
tery.
The windowpane is still dirty after cleaning?
• Is the micro fleece cloth dirty? Wash it.
• Are the windowpanes heavily soiled with grease or soot?
Add a mild cleaning agent, such as dishwasher liquid, to
the water in the spray bottle.
Water leaks from the lip?
• Hold the device vertically. Always rub the windowpane from
the top to the bottom.
I would like to use the device to clean other smooth surfaces.
• Avoid any damage and make sure the device is suitable for
the respective surface! Clean a hidden area first to check.
Cleaning
WARNING:
• Always disconnect the appliance from the mains adapter
before cleaning!
• Under no circumstances should you immerse the motor
housing in water in order to clean it. Otherwise this might
result in an electric shock or fire.
CAUTION:
• Do not use a wire brush or any abrasive items.
• Do not use any acidic or abrasive detergents.
• Empty the water tank and remove the micro fleece cloth.
• The micro fleece cloth can be machine-washed at 40°C.
• You can disconnect the motor housing from the wiper
assembly. In order to do so, turn the wiper assembly to the
"lock open" symbol.
• Rinse the water tank with clear water.
• Wipe all other surfaces with a damp cloth and mild cleaning
agent.
• Wait until all parts have dried completely and only then
reassemble the device!
Noise development
The sound pressure level in the ear of an operator (LpA) was
measured according to DIN EN ISO 3744.
Sound pressure level detected: 73 dB(A) (no limit)

Technical Data

Model: ............................................................................ WC 3528
Net weight: .............................................................. approx. 600 g
Mains adapter
Protection class: .......................................................................... II
Input: ........................................................ AC 220 – 240 V, 50 Hz
Output: ........................................................... DC 5.0 V, 170 mAh
Polarity: ...........................................................................
Battery: ........................................................3 x 1.2 V, 1500 mAh
Operating time: ............................................................40 minutes
Charging time: .................................................................16 hours
21
