20. Beatmatch View

The beatmatch view shows you the peaks of both tracks – the two displays are
arranged vis-à-vis. It is possible to quickly recognize whether bass drums and
snares are running simultaneously. This way, if the two tracks have been
matched regarding the pitch, it is possible to easily and quickly synchronise two
tracks. The left player 1 is displayed green and the right player 2 is displayed grey.

21. Complete View

In the complete view you can see the complete waveform of a track. The
dramatic arch of a track can be recognized well and at the blink of an eye you
can also see where the intros and breaks are. The elapsed part of a track is
displayed green and the remaining part of a track is displayed grey.

22. Needle View

The needle view is a zoomed view of the waveform display. This way it is easy to
recognize bass kicks for example.
The zoom range can be adjusted from 2 – 16 beats. To do so click the right mouse
button in needle view and select the according value from the submenu.
Furthermore you can choose whether the left, right, stereo or both channels
mixed should be shown in the waveform. Select the according option with a right
mouse click in needle view.
There are two types for the needle view display:
• Waveform Scrolling
The waveform moves. A vertical line in the middle represents the needle.
• Tick Scrolling
The waveform remains still. The line (corresponds to the needle's position)
moves.
NOTE!
This option is system resources saving.
Select the corresponding option with a right mouse click in needle view.

23. Master

Adjust the master volume for player 1 and player 2.
63
