12. PREPARING TO CHARGE
Lithium Iron Phosphate batteries CANNOT:
- RECEIVE HIGH CHARGE CURRENT OUTSIDE OF THE RATED NORMAL OPERATING RANGE OF 0
CHARGER THAT AUTOMATICALLY ADJUSTS CHARGE RATE ACCORDING AMBIENT TEMPERATURE.
- RECEIVE HIGH CHARGE CURRENT IF THE BATTERY WAS DISCHARGED BELOW ITS NOMINAL VOLTAGE. ONLY USE A CHARGER THAT
LOWERS CHARGE RATE IF MEASURED BATTERY VOLTAGE IS BELOW NOMINAL.
- BE OVERCHARGED. THE MAXIMUM ALLOWABLE VOLTAGE PER 3.2V CELL IS 3.6V i.e. a 12.8V battery has a maximum charged voltage of
14.4V. ONLY USE A CHARGER THAT AUTOMATICALLY LIMITS CHARGING VOLTAGE TO 3.6V per cell or LESS (14.4V for a 12.8V battery) AND
TERMINATES CHARGING ONCE THE BATTERY IS FULLY CHARGED.
a) If necessary to remove battery from vehicle to charge,always remove grounded terminal from battery first.
Make sure all accessories in the vehicle are off, so as not to cause an arc.
b) Be sure area around battery is well ventilated while battery is being charged. Ventilation for cooling purposes can be improved
by using a piece of cardboard or other non-metallic material as a fan.
c) Clean battery terminals. Be careful to keep corrosion from coming in contact with eyes.
d) Carefully follow manufacturer's recharging instructions.
e) Study all battery manufacturer's specific precautions and recommended rates of charge.
f) Determine voltage of battery by referring to vehicle or other user's manual and BEFORE MAKING THE BATTERY
CONNECTIONS , MAKE SURE THAT THE VOLTAGE OF THE BATTERY YOU ARE GOING TO CHARGE MATCHES THE
OUTPUT VOLTAGE OF THE CHARGER.
13. CHARGER LOCATION.
a) Locate charger as far away from battery as DC cables permit.
b) Never place charger directly above batterv being charged; chargers increase in temperature during operation and the heat will
transfer to the battery. c) Do not operate charger in a closed-in area or restrict ventilation in any way.
d) Do not set a battery on top of charger. IMPORTANT : Place charger on a hard flat surface or mount onto a vertical surface. Do not
place on plastic, leather or textile surface.
14. DC CONNECTION PRECAUTIONS
a) Connect and disconnect DC output clips only after setting any charger switches to off position and removing AC
cord from electric outlet. Never allow clips to touch each other, however should this happen no damage will result to
the charger circuit & the automatic charging programme will just reset to «start».
b) Attach clips to battery and chassis as indicated in 15(e), 15(f), and 16(b) through 16(d).
NOTE : This battery charger has an automatic safety feature that will prevent it from operating if the battery has been inversely
connected. Set charger switches to off position and/or remove AC cord from electrical outlet, disconnect the battery clips, then
reconnect correctly according to the instructions below.
15. FOLLOW THESE STEPS WHEN BATTERY IS INSTALLED IN VEHICLE. SHORT CIRCUITING OF THE
BATTERY TERMINALS MAY CAUSE BATTERY EXPLOSION. TO REDUCE RISK OF SHORT CIRCUITING THE
BATTERY :
a) Position AC and DC cords so as to reduce risk of damage by hood, door or moving engine part.
b) Stay clear of fan -blades, belts, pulleys, and other parts that can cause injury to persons.
c) Check polarity of battery posts. POSITIVE (POS, P, +) battery post usually has larger diameter than NEGATIVE (NEG,
N,–) post.
d) Determine which post of battery is grounded (connected) to the chassis. If negative post is grounded to chassis
(as in most vehicles),see (e). If positive post is grounded to the chassis,see (f).
e) For negative-grounded vehicle, connect POSITIVE (RED) clip from battery charger to POSITIVE (POS, P, + )
ungrounded post of battery. Connect NEGATIVE (BLACK) clip to vehicle chassis or engine block away from battery. Do not connect
clip to carburetor, fuel lines, or sheet-metal body parts. Connect to a heavy gage metal part of the frame or engine block.
f) For positive-grounded vehicle, connect NEGATIVE (BLACK) clip from battery charger to NEGATIVE (NEG. N , -)
ungrounded post of battery. Connect POSITIVE (RED) clip to vehicle chassis or engine block away from battery. Do
not connect clip to carburetor, fuel lines, or sheet-metal body parts. Connect to a heavy gage metal part of the
frame or engine block.
g) When disconnecting charger, turn switches to off, disconnect AC cord,remove clip from vehicle chassis,and then
remove clip from battery terminal.
h) See operating instructions for length of charge information.
16. FOLLOW THESE STEPS WHEN BATTERY IS OUTSIDE VEHICLE. SHORT CIRCUITING OF THE BATTERY
TERMINALS MAY CAUSE BATTERY EXPLOSION. TO REDUCE RISK OF SHORT CIRCUITING THE BATTERY :
a) Check polarity of battery posts. POSITIVE (POS, P, +) battery post usually has a larger diameter than NEGATIVE
(NEG,N, -) post.
b) This battery charger has an automatic safety feature that will prevent it from operating if the battery has been inversely
connected. The charger does allow charge current unless a voltage of at least 2V is sensed.
c) Connect POSITIVE (RED) charger clip to POSITIVE (POS, P, +) post of battery.
d) Connect NEGATIVE (BLACK) charger clip to NEGATIVE (NEG, N, -) battery post of the battery.
e) Do not face battery when making final connection.
f) When disconnecting charger, always do so in reverse sequence of connecting procedure & break first connection
while as far away from battery as practical.
g) A marine (boat) battery must be removed & charged on shore. To charge it on board requires equipment specially
designed for marine use.
4
O C / 32 O F TO 60 O C / 140 O F. ONLY USE A
