4. Specifications

EA490-200 5-Channel Amplifier
16
Seite 16
Rated Power Output (RMS)
Front / Rear Channels and
Subwoofer Channel at 4 ohms (13.8 V)
(THD = <1 %)
Rated Power Output (RMS)
Front / Rear Channels at 2 ohms and
Subwoofer Channel at 2 ohms (13.8 V)
(THD < = 0,1 %)
Damping Factor
Front / Rear Channels
Subwoofer Channel
at 4 Ohms
Signal-to-Noise Ratio (A-Filter)
Frequency Response
(Front- / Rear-
plus Subwoofer Channel)
(+0 dB / - 1 dB)
Channel Separation
Input Sensitivity
Integrated Cross-Over/Filtering
Slope Rate
Cross-Over Frequency
Fuse
Dimensions W x H x D
4 x 90 W (Satellites) / 1 x 200 W (Subwoofer)
4 x 125 W (Satellites) / 1 x 300 W (Subwoofer)
> 200
> 300
> 100 dB
10 Hz - 40 kHz
> 55 dB
200 mV - 4 V
High-Pass/ Front & Rear Channels
12 dB / Octave
continuously adjustable 50 - 250 Hz continuously adjustable 40 - 120 Hz
2 x 30 A
368 x 53 x 208 mm
Low-Pass Subwoofer Channel
24 dB / Octave
