Compass D3 plus Montageanleitung Seite 29

Teile-Nr. Beschreibung
02-0709 Ball Link
02-0810SG Thumb Screw (gold)
02-0813 Tail Boom Brace Connector
02-0814S Tail Boom Brace 530mm
02-0816T Vertical Fin Carbon (3Dplus)
02-0818 Tail cControl Rod Guide Clamp
02-0823AB Tail Boom Support Clamp
02-0826 Tail Boom 705mm
02-0850 Fiberglass Canopy (3D Plus)
02-0850P Painted FG Canopy (3DPlus)
02-0853 Canopy Rubber Grommet
05-0825T Horizontal Fin Carbon (3Dplus)
06-0851 Canopy Insert
40-2660 Tail Control Rod 2X660
80-0326 Cap Head Bolt M3x26
80-0332 Cap Head Bolt M3x32
80-2508 Cap Head Bolt M2.5x8
82-3201 Washer 3.2x10x1.2
91-0003 Nylon Lock Nut M3
95-2508 Self Tapping Bolt 2.5x8
Bestell-Nr. Bestell-Beschreibung
Ball Links
02-0709
Thumb Screw set (gold)
02-0810SG
02-0813S Tail Boom Brace Connector set
02-0814S Tail Boom Brace set 530mm
02-0816T Vertical Fin Carbon (3Dplus)
Tail cControl Rod Guide Clamp set
02-0818S
Tail Boom Support Clamp
02-0823AB
02-0826 Tail Boom 705mm
02-0850 Fiberglass Canopy (3D Plus)
02-0850P Painted FG Canopy (3D Plus)
02-0853 Canopy Rubber Grommet set
Horizontal Fin Carbon (3Dplus)
05-0825T
06-0851 Canopy Insert
40-2660S Tail Control Rod 2X660
80-0326 Cap Head Bolts M3x26
80-0332 Cap Head Bolts M3x32
Cap Head Bolts M2.5x8
80-2508
82-3201 Washers 3.2x10x1.2
91-0003 Nylon Lock Nuts M3
95-2508 Self Tapping Bolts 2.5x8
Menge
10 pcs/bag
4 pcs/bag
4 pcs/bag
2 pcs/bag
1 pcs/bag
4 pcs/bag
1 set/bag
2 pcs/bag
1 pcs/bag
1 pcs/bag
10 pcs/bag
1 pcs/bag
1 set/bag
1 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
