Compass D3 plus Montageanleitung Seite 23

Teile-Nr. Beschreibung
02-0205 Tail Blade Link
02-0209 Tail Rotor Hub
02-0213 Tail Pitch Slider
02-0214 Tail Shaft
02-0225 Grooved Pin
02-0229 Gear box frame
02-0230 Tail hinge
02-0250 Tail Blade
02-0262 Tail rotor pulley
02-0264AB Tail blade holder
02-0701 Stainless Link Ball
02-1211 Tail pitch plate w, BB
02-8205 Tail Pitch Control unit
02-8206 Tail Case Set
05-0227 Gear box set
05-0229 Tail pitch slider
05-0231 Gear Box Member
06-0208 Tail pitch arm
06-0213 Tail pitch H arm
Guide Pin Bolt
06-0222
60-3092 Ball Bearing 3x9x2.5
60-4094 Ball Bearing 4x9x4
60-7113 Ball Bearing 7x11x3
61-5134 Flanged Bearing 5x13x4
63-4094 Thrust Bearing 4x9x4
Cap Head Bolt M2x8
80-0208S Cap Head Bolt M2x8
Cap head Bolt M3x14
Cap Head Bolt M2.5x6
Cap Head Bolt M2.5x8
Set Screw
Washer 3.2x5.2x0.3
Washer 5x8x0.4
Washer 5x8x0.8
Hexagonal nut2x1
Nylon Lock Nut M3
Tail belt 3M1800 Bando
Bestell-Nr. Bestell-Beschreibung
02-0205S Tail Blade Links w, Pin
02-0209 Tail Rotor Hub
Tail Pitch Slider
02-0213
Tail Shafts
02-0214
02-0205S Provided w, 02-0205S
02-0229Z Gear box frame w, BB
02-0230S Tail Hing with Pin
Tail Blade set
02-0250
Tail rotor pulley with spring pin
02-0262S
02-0264AB Tail blade holder
02-0701 Stainless Link Balls
02-1211 Tail pitch plate w, BB
Tail Pitch Control unit
02-8205
Tail Case Set
02-8206
05-8227Z Gear box set
05-0229S Tail Pitch Slider w. BB
05-0231 Gear Box Member
Tail pitch arm w, H-arm & Pin
06-0213S
Tail pitch arm w, H-arm & Pin
06-0213S
Guide Pin Bolts
06-0222
60-3092 Ball Bearings 3x9x2.5
60-4094 Ball Bearings 4x9x4
Ball Bearings 7x11x3
60-7113
Flanged Bearings 5x13x4
61-5134
63-4094 Thrust Bearings 4x9x4
80-0208 Cap Head Bolts M2x8
80-0208S Cap Head Bolts M2x8
80-0314 Cap head Bolts M3x14
Cap Head Bolts M2.5x6
80-2506
80-2508 Cap Head Bolts M2.5x8
81-0305 Set Screw
82-3402 Washer 3.2x5.2x0.3
82-5804 Washer 5x8x0.4
Washer 5x8x0.8
82-5808
90-0201 Hexagonal nut2x1
91-0003 Nylon Lock Nuts M3
98-1800B Tail belt 3M1800 Bando
Menge
2 pcs/bag
1 pcs/bag
1 pcs/bag
2 pcs/bag
1 set/bag
1 set/bag
2 pcs/bag
1 pcs/bag
2 pcs/bag
10 pcs/bag
1 pcs/bag
1 set/bag
1 set/bag
1 set/bag
1 pcs/bag
2 pcs/bag
1 set/bag
1 set/bag
2 pcs/bag
4 pcs/bag
5 pcs/bag
2 pcs/bag
2 pcs/bag
2 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
1 pcs/bag
