Compass D3 plus Montageanleitung Seite 21

Teile-Nr. Beschreibung
02-0109 Delrin Dampener 8mm
02-0110 Spindle Washer 8mm
02-0113 Spindle Shaft 8mm
02-0118 Flybar Collar
02-0507 Mixing Arm
02-0511 Paddle Insert
02-0531 Mixing Arm Bushing
02-0536G Flybar Holder
02-0539 Flybar Collar
02-0540 Flybar Control Arm
02-0543 Flybar
02-0553 Paddle
02-0701 Stainless Link Ball
02-1103 Main Blade Holder 8mm
02-1538 Control Ball Spacer
07-0106 Rotor Hub
60-3083 Ball Bearing 3x8x3
60-4083 Ball Bearing 4x8x3
60-8165 Ball Bearing 8x16x5
61-4083 Flanged Bearing 4x8x3
63-8165 Thrust Bearing 8x16x5
79-0308 Button Head Bolt M3×8
79-0510 Button Head Bolt M5x10
80-0206S Cap Head Bolt M2x6
80-0208S Cap Head Bolt M2x8
80-0310 Cap Head Bolt M3x10
80-0322 Shanked Bolt M3x22
80-0428 Shanked Bolt M4×28
80-2514 Cap Head Bolt M2.5×14
81-0304 Set Screw M3x4
81-0404 Set Screw M4x4
82-2562 Washer 2.6x5.2x0.3
82-5131 Washer 5.3×13×1
82-821003 Washer 8.2×10×0.3
91-0003 Nylon Lock Nut M3
91-0004 Nylon Lock Nut M4
97-0920 Rubber O-Ring 13×9×2
Bestell-Nr. Bestell-Beschreibung
02-0109 Delrin Dampeners 8mm
Spindle Washers 8mm
02-0110
02-0113 Spindle Shafts 8mm
02-0118 Flybar Collars
02-0507 Mixing Arm set
02-0553S Paddle set
Bushing set (3 sizes)
02-0531S
02-0536G Flybar Holder w; Bearings
02-0539 Flybar Collars
02-0540s Flybar Control Arm set
02-0543 Flybars
Paddle set
02-0553S
02-0701 Stainless Link Balls
Main Blade Holder set 8mm
02-1103
02-1538 Control Ball Spacer set
07-0106 Rotor Hub set
Ball Bearings 3x8x3
60-3083
60-4083 Ball Bearings 4x8x3
60-8165 Ball Bearings 8x16x5
61-4083 Flanged Bearings 4x8x3
63-8165 Thrust Bearings 8x16x5
Button Head Bolts M3×8
79-0308
79-0510 Button Head Bolts M5x10
Cap Head Bolts M2x6
80-0206S
80-0208s Cap Head Bolt M2x8
80-0310 Cap Head Bolts M3x10
Shanked Bolts M3x22
80-0322
80-0428 Shanked Bolts M4×28
Cap Head Bolts M2.5×14
80-2514
81-0304 Set Screws M3x4
81-0404 Set Screws M4x4
Washers 2.6x5.2x0.3
82-2562
82-5131 Washers 5.3×13×1
Washers 8.2×10×0.3
82-821003
91-0003 Nylon Lock Nuts M3
91-0004 Nylon Lock Nuts M4
97-0920 Rubber O-Ring set 13×9×2
Menge
2 pcs/bag
2 pcs/bag
2 pcs/bag
2 pcs/bag
2 pcs/bag
2 pcs/bag
6 pcs/bag
1 pcs/bag
2 pcs/bag
2 pcs/bag
2 pcs/bag
2 pcs/bag
10 pcs/bag
2 pcs/bag
2 pcs/bag
1 set/bag
5 pcs/bag
5 pcs/bag
2 pcs/bag
5 pcs/bag
2 set/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
2 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
10 pcs/bag
2 pcs/bag
10 pcs/bag
10 pcs/bag
4 pcs/bag
